System And Components
143-3501 LINES GP-PROPELS/N 9AL1-276
Group No: 143-3501
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V9835 | 1 TEE | 1 | |
| 6V9849 | 2 ELBOW | 2 | |
| 8T8902 | 3 ADAPTER-TEE | 1 | |
| 8T6446 | 4 UNION | 6 | |
| 6V8647 | 5 CONNECTOR | 9 | |
| 6V8633 | 6 CONNECTOR | 1 | |
| 6V9007 | 7 ELBOW | 2 | |
| 6V9839 | 8 TEE-SWIVEL | 1 | |
| 8T5429 | 9 ELBOW | 5 | |
| 6V8641 | 10 CONNECTOR | 3 | |
| 6V9010 | 11 CONNECTOR-PORT | 4 | |
| 6V8627 | 12 ELBOW | 2 | |
| 6V8724 | 13 ELBOW | 1 | |
| 6V8638 | 14 CONNECTOR | 5 | |
| 6V8721 | 15 ELBOW | 1 | |
| 6V8636 | 16 CONNECTOR | 3 | |
| 3J7354 | 17 SEAL-O-RING | 13 | |
| 7M8485 | 18 SEAL-O-RING | 2 | |
| 3D2824 | 19 SEAL-O-RING | 8 | |
| 3J1907 | 20 SEAL-O-RING | 17 | |
| 2M9780 | 21 SEAL-O-RING | 6 | |
| 4J5477 | 22 SEAL-O-RING | 45 | |
| 5K9090 | 23 SEAL-O-RING | 4 | |
| 6V8398 | 24 SEAL-O-RING | 14 | |
| 6V8397 | 25 SEAL-O-RING | 8 | |
| 6V9837 | 26 TEE-SWIVEL | 1 | |
| 1P3703 | 27 SEAL-RECTANGULAR | 8 | |
| 1P5766 | 28 FLANGE-HALF | 16 | |
| 8C6865 | 29 CONNECTOR | 1 | |
| 1035831 | 30 VALVE GP-DIFFERENTIAL LOCK | 1 | |
| 7X0264 | 31 BOLT (1/4-20X2.5-IN) | 2 | |
| 8T4205 | 32 WASHER-HARD (7.2X14.5X2-MM THK) | 20 | |
| 6V8185 | 33 NUT (1/4-20-THD) | 11 | |
| 1034924 | 34 VALVE GP-CONTROL (PROPEL) | 1 | |
| 7X0279 | 35 BOLT (5/16-18X4.75-IN) | 3 | |
| 8T4224 | 36 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 6V8189 | 37 NUT (5/16-18-THD) | 3 | |
| 8C1020 | 38 CLAMP-TUBE | 2 | |
| 7X0265 | 39 BOLT (1/4-20X2.75-IN) | 2 | |
| 5E8486 | 40 CLAMP AS | 1 | |
| 1022778 | 41 CYLINDER AS-HYDRAULIC | 1 | |
| 1D5121 | 42 NUT-JAM (7/8-14-THD) | 1 | |
| 8T4121 | 43 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 1028972 | 44 FILTER GP-OIL (HYDRAULIC) | 2 | |
| 8M3267 | 45 SCREW-HEX SOCKET (3/8-16X0.75-IN) | 8 | |
| 1071972 | 46 CLAMP | 2 | |
| 1071973 | 47 CLAMP | 1 | |
| 1071978 | 48 CLAMP | 2 | |
| 7X0266 | 49 BOLT (1/4-20X3-IN) | 6 | |
| 8T5360 | 50 WASHER (12X22.5X2.5-MM THK) | 32 | |
| 1078261 | 51 TUBE AS | 1 | |
| 1114326 | 52 HOSE AS | 1 | |
| 6V9850 | 53 ELBOW | 1 | |
| 1073805 | 54 HOSE AS | 1 | |
| 1073808 | 55 HOSE AS | 1 | |
| 1073804 | 56 HOSE AS | 3 | |
| 1078258 | 57 HOSE AS | 3 | |
| 1081856 | 58 HOSE AS | 1 | |
| 1114470 | 59 HOSE AS | 2 | |
| 1078259 | 60 HOSE AS | 1 | |
| 1073802 | 61 HOSE AS | 1 | |
| 1078260 | 62 HOSE AS | 1 | |
| 1073806 | 63 HOSE AS | 1 | |
| 1073800 | 64 HOSE AS | 1 | |
| 8C6877 | 65 BOLT (7/16-14X1.75-IN) | 32 | |
| 1078262 | 66 HOSE AS | 2 | |
| 1078263 | 67 HOSE AS | 1 | |
| 1078257 | 68 HOSE AS | 4 | |
| 1006621 | 69 HOSE AS | 1 | |
| 1432885 | 70 BRACKET AS | 1 | |
| 8T4137 | 71 BOLT (M10X1.5X20-MM) | 2 | |
| 1079070 | 72 HOSE AS | 1 | |
| 1079071 | 73 HOSE AS | 1 | |
| 7D9212 | 74 SPRING | 1 | |
| 3E7433 | 75 ELBOW | 1 | |
| 8I0788 | 76 MOTOR GP-PISTON (PROPEL) | 2 | |
| 5P2566 | 77 BOLT (1/2-13X1.5-IN) | 8 | |
| 8T4223 | 78 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 8I0838 | 79 PUMP GP-PISTON (PROPEL, RH) | 1 | |
| 8I0839 | 80 PUMP GP-PISTON (PROPEL, LH) | 1 | |
| 8T8917 | 81 BOLT (1/2-13X1.25-IN) | 8 | |
| 2P1279 | 82 LOCKNUT (9/16-18-THD) | 6 | |
| 6V8635 | 83 CONNECTOR | 2 | |
| 6V9840 | 84 TEE-SWIVEL | 1 | |
| 6K6307 | 85 SEAL-O-RING | 1 | |
| 5M3062 | 86 BOLT (3/8-16X0.75-IN) | 1 | |
| 7X2444 | 87 TEE-SWIVEL | 2 | |
| 6V3965 | 88 FITTING (QUICK DISCONNECT) | 6 | |
| 1096640 | 89 HOSE AS | 1 | |
| 6V9746 | 90 SEAL-O-RING | 4 | |
| 6V8400 | 91 SEAL-O-RING | 1 | |
| 8S7374 | 92 FILTER AS-AIR (DRIVE SHAFT) | 1 | |
| 1114409 | 93 ROD | 1 | |
| 1114411 | 94 SPRING | 1 | |
| 3E9865 | 95 LOCKNUT (1/4-20-THD) | 1 | |
| 6V8186 | 96 NUT-FULL (5/16-24-THD) | 1 | |
| 7X2501 | 97 BOLT (1/4-20X1.25-IN) | 1 | |
| 5P4115 | 98 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 6V8801 | 99 NUT (3/8-16-THD) | 1 | |
| 5E0114 | 100 CLAMP | 2 | |
| 7J6285 | 101 SEAL-O-RING | 2 | |
| 8C5237 | 102 SEAL-O-RING | 1 | |
| 6V9842 | 103 TEE-SWIVEL | 3 | |
| 5E2176 | 104 CLAMP | 2 | |
| 6V0852 | 105 CAP-DUST | 6 | |
| 8T4896 | 106 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 1121794 | 107 HOSE AS | 1 | |
| 1121795 | 108 HOSE AS | 1 | |
| 1S0994 | 109 CLIP (LOOP) | 2 | |
| 8J1256 | 110 CLIP | 2 | |
| 0778184 | 111 CLAMP | 2 | |
| 8T4192 | 112 BOLT (M12X1.75X25-MM) | 2 | |
| 6V8935 | 113 REDUCER | 1 | |
| 6V8554 | 114 NUT (13/16-16-THD) | 1 | |
| 1135995 | 115 HOSE AS | 2 | |
| 8T2335 | 116 ELBOW | 2 | |
| 8T6663 | 117 ADAPTER-PORT | 2 | |
| 1125375 | 118 PLATE AS | 1 | |
| 1402238 | 119 RESISTOR AS | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 6V2480 | 120 SCREW (4-40X0.5-IN) | 2 | |
| 6B4540 | 121 NUT (4-40-THD) | 2 | |
| 0874683 | 122 LOCKWASHER | 2 |
