System And Components
479-9017 TANK GP-DIESEL EXHAUST FLUIDS/N 4861-UP; 4871-UP
Group No: 479-9017
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3875472 | 1 LANYARD | 1 | |
| 3983011 | 2 CAP-TANK FILLER (DIESEL EXHAUST FLUID) | 1 | |
| 4209173 | 3 BRACKET | 1 | |
| 4209180 | 4 PLATE | 1 | |
| 4390668 | 5 INSULATION | 1 | |
| 4390669 | 6 INSULATION | 1 | |
| 4460473 | 7 ADAPTER AS | 1 | |
| 4512774 | SCREEN AS | 1 | |
| 4489386 | 8 INSULATION | 1 | |
| 4489392 | 9 INSULATION | 1 | |
| 4500232 | 10 INSULATION | 1 | |
| 4500237 | 11 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4500238 | 12 INSULATION | 1 | |
| 4799019 | 13 TANK GP-DIESEL EXHAUST FLUID | 1 | |
| 4812527 | 14 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 6 | |
| 4818615 | 15 HOSE | 1 | |
| 4819950 | 16 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 5P0597 | 17 CLAMP-HOSE | 2 | |
| 5P4116 | 18 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7X7729 | 19 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 21 NUT (M10X1.5-THD) | 2 | |
| 8T4138 | 22 BOLT (M6X1X20-MM) | 6 | |
| 8T4189 | 23 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4195 | 24 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 25 BOLT (M10X1.5X35-MM) | 2 | |
| 9X8256 | 26 WASHER (6.6X12X2-MM THK) | 6 |
