System And Components
374-1398 LINES GP-DIESEL EXHAUST FLUIDS/N JFC1-UP
Group No: 374-1398
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 4 | |
| 1028705 | 2 PLATE (TOP) | 3 | |
| 1111777 | 3 BUMPER-RUBBER | 1 | |
| 1772215 | 4 STRAP-DUAL CLAMP | 5 | |
| 2082683 | 5 SPACER (13.9X21.3X46-MM THK) | 2 | |
| 2567669 | 6 PLATE | 4 | |
| 2567670 | 7 SPACER | 2 | |
| 2895248 | 8 CAM | 1 | |
| 3260314 | 9 CONNECTOR AS | 1 | |
| 4K1388 | SEAL-O-RING | 1 | |
| 3260313 | CONNECTOR | 1 | |
| 3875472 | 10 LANYARD | 1 | |
| 3896955 | 11 LOCK AS | 1 | |
| 3899523 | 12 DOOR | 1 | |
| 3920915 | 13 STRAP AS | 1 | |
| 3920916 | 14 STRAP AS | 1 | |
| 3920933 | 15 PAD | 1 | |
| 3921785 | 16 HOSE AS | 1 | |
| 3971529 | 17 FOAM | 1 | |
| 3978286 | 18 PLATE | 1 | |
| 3978287 | 19 PLATE | 2 | |
| 3979110 | 20 PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 6 | |
| 3983011 | 21 CAP-TANK FILLER (DIESEL EXHAUST FLUID) | 1 | |
| 4159349 | 22 PLATE | 3 | |
| 4159350 | 23 BAFFLE | 1 | |
| 4176359 | 24 HOSE AS | 1 | |
| 4264053 | 25 ELBOW AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 2977987 | ELBOW | 1 | |
| 4457647 | 26 HOSE | 1 | |
| 4460473 | 27 ADAPTER AS | 1 | |
| 4512774 | SCREEN AS | 1 | |
| 4510501 | 28 VALVE AS-BALL (DEF DRAIN) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4652702 | 29 COVER AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 6 | |
| 4652704 | 30 PLATE AS | 1 | |
| 7T1099 | LINK | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4880909 | 31 PLATE | 1 | |
| 4880910 | 32 INSULATION | 1 | |
| 4880911 | 33 INSULATION | 1 | |
| 4880912 | 34 INSULATION | 1 | |
| 4880913 | 35 INSULATION | 1 | |
| 2964090 | 36 HINGE AS | 2 | |
| 0993649 | 37 BOLT (M8X1.25X40-MM) | 2 | |
| 1488365 | 38 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 8T6876 | ELBOW | 1 | |
| 1504043 | 39 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 4V0611 | 40 CLAMP | 2 | |
| 2888405 | 41 CLAMP-HALF | 4 | |
| 3514322 | 42 CLIP (LOOP) | 2 | |
| 3J7354 | 43 SEAL-O-RING | 1 | |
| 4I0472 | 44 CLIP (LOOP) | 1 | |
| 4P7581 | 45 CLIP (LADDER) | 2 | |
| 5M3062 | 46 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P4116 | 47 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 6D4246 | 48 CLIP (LOOP) | 7 | |
| 6S8620 | 49 CLAMP-HOSE | 3 | |
| 6V5217 | 50 BOLT (M8X1.25X20-MM) | 6 | |
| 7X0818 | 51 BOLT (M8X1.25X45-MM) | 3 | |
| 7X2621 | 52 BOLT (M10X1.5X12-MM) | 2 | |
| 7X7729 | 53 WASHER (11X25X3-MM THK) | 8 | |
| 8M2773 | 55 CLIP (LOOP) | 1 | |
| 8T4121 | 56 WASHER-HARD (11X21X2.5-MM THK) | 26 | |
| 8T4136 | 57 BOLT (M10X1.5X25-MM) | 17 | |
| 8T4137 | 58 BOLT (M10X1.5X20-MM) | 10 | |
| 8T4138 | 59 BOLT (M6X1X20-MM) | 6 | |
| 8T4195 | 60 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4224 | 61 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 8T4896 | 62 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T5005 | 63 BOLT (M10X1.5X70-MM) | 2 | |
| 9M0164 | 64 CLAMP-HOSE | 2 | |
| 8T4908 | 65 BOLT (M8X1.25X25-MM) | 8 | |
| 9X8256 | 66 WASHER (6.6X12X2-MM THK) | 6 | |
| 6V8523 | 67 HOSE (288-CM) | ||
| 6V8523 | 67A HOSE (78.7-CM) | ||
| 7X7877 | 68 STRIP-EDGE (10-CM) | ||
| 7X7877 | 68A STRIP-EDGE (14-CM) | ||
| 7X7877 | 68B STRIP-EDGE (50-CM) |
