System And Components
433-3058 CONTROL & MTG GP-ELHYDS/N WCS1-201
Group No: 433-3058
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1728591 | 1 NUT-CLIP (M6X1-THD) | 2 | |
| 7K1181 | 2 STRAP-CABLE | 4 | |
| 2689368 | 3 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 6 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 2777273 | 4 ROD | 1 | |
| 2826685 | 5 COVER (INSIDE) | 1 | |
| 2826687 | 6 COVER (OUTSIDE) | 1 | |
| 2900813 | 7 FILM-INSTRUCTION (CONSOLE TILT) | 1 | |
| 2928118 | 8 CUSHION AS | 1 | |
| 3675533 | 9 LEVER AS | 1 | |
| 3691863 | 10 CABLE AS | 1 | |
| 3691864 | 11 CLIP | 1 | |
| 3767657 | 12 CONTROL GP-STEERING | 1 | |
| 4321217 | 13 SUPPORT GP-STEERING CONTROL | 1 | |
| 4326162 | 14 BRACKET | 1 | |
| 4326163 | 15 CONTROL GP-STIC LOCKOUT | 1 | |
| 4332250 | 16 WIRING GP-STIC CONTROL | 1 | |
| 1376723 | 17 SCREW-FLAT HEAD (6-32X0.5-IN) | 2 | |
| 1388454 | 18 SCREW-TRUSS HEAD (M4X0.7X10-MM) | 2 | |
| 5P7970 | 19 NUT (M8X1.25-THD) | 2 | |
| 6V5220 | 20 BOLT (M8X1.25X65-MM) | 1 | |
| 8T4224 | 21 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 8T4908 | 22 BOLT (M8X1.25X25-MM) | 4 | |
| 9X1046 | 23 SCREW (M4X0.7X18-MM) | 1 | |
| 9X2043 | 24 SCREW-TRUSS HEAD (M6X1X14-MM) | 2 | |
| 9X2044 | 25 SCREW-TRUSS HEAD (M6X1X16-MM) | 6 | |
| 9X2045 | 26 SCREW-TRUSS HEAD (M6X1X20-MM) | 2 | |
| 6K8179 | 27 CLIP | 1 |
