Assembly
100%

480-6550 BATTERY & WIRING GPS/N N1S1-UP

Group No: 480-6550
Part NumberPart NameQty
9U14691 CLAMP4
29055622 MOUNT (DUAL SWIVEL)1
36940983 SWITCH AS-DISCONNECT (MASTER)1
2H3922LOCKWASHER1
6F7045NUT-FULL (3/8-24-THD)2
8H5303NUT (3/4-16-THD)2
4498192KIT-KNOB (DISCONNECT SWITCH)1
48462974 PANEL AS1
6V9632NUT-WELD (M6X1-THD)4
48549235 BAR1
48607416 CABLE AS (BATTERY POSITIVE)1
1598053CABLE-ELECTRICAL (0000-GA, RED)(263-CM)
3482310TERMINAL AS-RING1
0319295TERMINAL-RING (0000-GA, 3/8-IN SCREW)1
1355010TUBE-HEAT SHRINK (52-MM DIA)(5-CM)
3482317TERMINAL AS-RING1
3L7634TERMINAL-RING (0000-GA, 1/2-IN SCREW)1
1355010TUBE-HEAT SHRINK (52-MM DIA)(5-CM)
3519309TUBE-HEAT SHRINK (32-MM DIA)(9-CM)
48607427 CABLE AS (BATTERY NEGATIVE)1
0319295TERMINAL-RING (0000-GA, 3/8-IN SCREW)1
1598054CABLE-ELECTRICAL (0000-GA, BLACK)(286-CM)
3482317TERMINAL AS-RING1
3L7634TERMINAL-RING (0000-GA, 1/2-IN SCREW)1
1355010TUBE-HEAT SHRINK (52-MM DIA)(5-CM)
17836208 STRAP-DUAL CLAMP3
20422819 STRAP-CABLE2
2G876710 WASHER (10.5X60X3-MM THK)8
344567511 NUT (M10X1.5-THD)1
3K606012 LOCKNUT (3/8-16-THD)1
5C955313 BOLT (M6X1X16-MM)2
6G226314 SPACER (10.5X19X28.5-MM THK)4
8T412115 WASHER-HARD (11X21X2.5-MM THK)2
8T418516 BOLT (M10X1.5X50-MM)3
8T543617 BOLT (M10X1.5X130-MM)1
8W125318 SPACER (11.06X15.88X60-MM THK)1
9X825619 WASHER (6.6X12X2-MM THK)2
