System And Components
472-1634 LINES GP-DIESEL EXHAUST FLUIDS/N D261-205
Group No: 472-1634
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T7860 | 1 BUSHING-REDUCER | 1 | |
| 2617990 | 2 GROMMET | 1 | |
| 2977987 | 3 ELBOW | 2 | |
| 3650159 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3650162 | 5 CONNECTOR-SPECIAL | 2 | |
| 3652226 | 6 HOSE AS | 1 | |
| 4246232 | BUTTON (RELEASE) | 2 | |
| 3892659 | 7 HOSE AS | 1 | |
| 3892660 | 8 HOSE AS | 1 | |
| 3893719 | 9 ELBOW AS | 1 | |
| 0905725 | ELBOW | 1 | |
| 6V3250 | SEAL-O-RING | 1 | |
| 3983011 | 10 CAP-TANK FILLER (DIESEL EXHAUST FLUID) | 1 | |
| 4182186 | 11 HOSE | 1 | |
| 4182189 | 12 HOSE | 1 | |
| 4510501 | 13 VALVE AS-BALL (DEF DRAIN) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 4699108 | 14 TANK AS-COOLANT | 1 | |
| 4913429 | 15 BRACKET AS | 1 | |
| 4749783 | 16 HOSE AS | 1 | |
| 0672551 | 17 CLIP | 6 | |
| 1004838 | 18 BOLT (M6X1X20-MM) | 2 | |
| 1498142 | 19 CONNECTOR | 1 | |
| 1503026 | 20 ELBOW AS | 1 | |
| 6V4292 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1557321 | 21 ADAPTER AS | 1 | |
| 6V1722 | ADAPTER | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1999751 | 22 SEAL-O-RING | 1 | |
| 1S0994 | 23 CLIP (LOOP) | 8 | |
| 2A2677 | 24 SPACER (10.7X17.14X19.05-MM THK) | 1 | |
| 3432386 | 25 CLIP (LOOP) | 4 | |
| 3875467 | 26 LANYARD | 1 | |
| 3D5279 | 27 GROMMET | 2 | |
| 4D5980 | 28 GROMMET | 1 | |
| 5D1026 | 29 CLAMP-BAND | 5 | |
| 5P4325 | 30 CLIP (LOOP) | 3 | |
| 9X8256 | 31 WASHER (6.6X12X2-MM THK) | 3 | |
| 6I0631 | 32 BOLT (M6X1X12-MM) | 2 | |
| 6S8620 | 33 CLAMP-HOSE | 8 | |
| 6V0301 | 34 ADAPTER | 1 | |
| 6V5064 | 35 SEAL-O-RING | 1 | |
| 6V6609 | 36 SEAL-O-RING | 2 | |
| 6V9027 | 37 SEAL-O-RING | 2 | |
| 6V9028 | 38 SEAL-O-RING | 1 | |
| 7X2503 | 39 CLIP | 2 | |
| 8T0119 | 40 ELBOW | 1 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4133 | 42 NUT (M10X1.5-THD) | 3 | |
| 8T4136 | 43 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4138 | 44 BOLT (M6X1X20-MM) | 2 | |
| 8T4224 | 45 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T4908 | 46 BOLT (M8X1.25X25-MM) | 1 | |
| 8T4971 | 47 BOLT (M6X1X30-MM) | 1 | |
| 8T7863 | 48 CONNECTOR | 1 | |
| 8T4191 | 49 BOLT (M10X1.5X16-MM) | 2 | |
| 9X2133 | 50 HOSE (166-CM) | ||
| 6V8523 | 51 HOSE (243-CM) | ||
| 6V8523 | 51A HOSE (72-CM) | ||
| 3496234 | 52 HOSE (305-CM) | ||
| 3496234 | 52A HOSE (290-CM) | ||
| 3650268 | 53 INSULATION-BULK (145-CM) |
