System And Components
329-8423 HOUSING GP-FRONTS/N J9G1-UP
Group No: 329-8423
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 16 | |
| 6I0645 | 2 BOLT (M8X1.25X25-MM) | 3 | |
| 6I0789 | 3 BOLT (M10X1.5X60-MM) | 3 | |
| 7C4616 | 4 BOLT (M12X1.75X45-MM) | 1 | |
| 0676179 | 5 DOWEL | 1 | |
| 1003751 | 6 BOLT (M8X1.25X65-MM) | 5 | |
| 1013895 | 7 BOLT (M8X1.25X35-MM) | 2 | |
| 1331011 | 8 WASHER | 1 | |
| 2323666 | 9 WASHER-THRUST | 1 | |
| 3254374 | 10 PLATE-THRUST | 1 | |
| 3304778 | 11 GASKET | 1 | |
| 3400571 | 12 GEAR (72-TEETH)(CAMSHAFT) | 1 | |
| 3421306 | 13 IDLER AS (97-TEETH) | 1 | |
| 4190423 | 14 HUB-IDLER GEAR | 1 | |
| 5025408 | 15 CASE-GEAR | 1 | |
| 3489985 | 16 GASKET | 1 | |
| 3718059 | 17 COVER-FRONT | 1 | |
| 3718062 | 18 SEAL | 1 |
