432-1410 RADIATOR GPS/N J9G1-UP

Group No: 432-1410
Part NumberPart NameQty
6I06541 BOLT (M10X1.5X25-MM)3
10044582 BOLT (M8X1.25X14-MM)4
10044613 BOLT (M10X1.5X50-MM)2
10175414 SCREW-FLAT HEAD (M8X1.25X25-MM)4
10175465 MOUNT2
12438156 BOLT (M8X1.25X16-MM)5
28383027 BOLT (M16X2X80-MM)4
35875788 HOSE3
35938629 HOSE (UPPER RADIATOR)1
359386310 HOSE (LOWER RADIATOR)1
366940311 PIPE AS1
369378112 GUARD (RH)(RH)1
369446113 BRACKET1
369447114 RADIATOR & AFTERCOOLER GP1
369750115 HOSE1
382722216 GUARD AS (LH)(LH)1
1953699NUT (M8X1.25-THD)2
3634208BOLT (M8X1.25X40-MM)2
382746017 MOUNT2
387642818 BRACKET1
103671419 CLIP4
390025120 BOLT-FLANGE HEAD (M8X1.25X40-MM)4
444140321 PIPE1
587104422 BAFFLE1
468506823 BRACKET1
6I021724 BOLT (M8X1.25X20-MM)2
6I059425 NUT (M10X1.5-THD)4
5P411626 WASHER-HARD (8.8X20.5X2-MM THK)4
8T498427 CLAMP-HOSE6
8T670328 CLAMP-HOSE2
