System And Components
503-7522 CASE GP-TRANSMISSIONPART OF 503-7509, 530-3040 CASE & PARTS GP-PLANETARY
Group No: 503-7522
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6T9202 | 1 PLUG | 2 | |
| 6Y1896 | 2 PLUG AS-DRAIN (TRANSMISSION) | 2 | |
| 5P6718 | SEAL-O-RING | 1 | |
| 7T2651 | 3 STRAINER-SUCTION (TRANSMISSION) | 1 | |
| 7T3253 | 4 DOWEL | 2 | |
| 9W5460 | 5 RING | 1 | |
| 1069861 | 6 PLATE AS-COVER | 1 | |
| 1209762 | 7 SEAL-O-RING | 3 | |
| 1470206 | 8 SPRING | 1 | |
| 1470211 | 9 ELBOW AS | 1 | |
| 3G6927 | ADAPTER | 1 | |
| 3423830 | ADAPTER | 1 | |
| 1470218 | 10 TUBE AS | 1 | |
| 1470232 | 11 PLUG | 2 | |
| 1470234 | 12 BOLT (9/16-18X0.83-IN) | 2 | |
| 1470236 | 13 TUBE AS | 1 | |
| 1470262 | 14 WASHER (19.1X24.1X1.5-MM THK) | 4 | |
| 1470266 | 15 BOLT (3/4-16X1.417-IN) | 2 | |
| 2T2695 | 16 SEAL-O-RING | 2 | |
| 2059244 | 17 PLUG | 1 | |
| 2387561 | 18 BOLT | 2 | |
| 2744556 | 19 PLUG AS | 3 | |
| 8L2786 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 2938745 | 20 PLUG-PROTECTION | 2 | |
| 4664938 | 21 SEAL-LIP TYPE | 1 | |
| 3343059 | 22 PLUG | 1 | |
| 3345131 | 23 PLUG AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 3779141 | 24 CASE AS-FRONT | 1 | |
| 3344963 | PLUG | 4 | |
| 3344979 | PLUG | 4 | |
| 3707748 | CASE-FRONT | 1 | |
| 3781440 | TUBE | 1 | |
| 3888316 | 25 PLUG | 1 | |
| 3888318 | 26 HOUSING | 1 | |
| 3888319 | 27 COUPLING | 1 | |
| 3888322 | 28 GAUGE-OIL LEVEL (DIPSTICK) | 1 | |
| 3888323 | 29 TUBE-DIPSTICK | 1 | |
| 3888324 | 30 PLUG AS | 1 | |
| 3915877 | SEAL-O-RING | 1 | |
| 3888325 | 31 SWITCH-PRESSURE (TRANSMISSION) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3888447 | 32 FILTER-OIL (TRANSMISSION)(TRANSMISSION) | 1 | |
| 7W3556 | 33 WASHER (14.27X20.57X1.5-MM THK) | 4 | |
| 3888543 | 34 BALL | 1 | |
| 3915870 | 35 SEAL-O-RING | 1 | |
| 3915885 | 36 PLATE | 1 | |
| 1053478 | 37 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 4 | |
| 0964833 | 38 BOLT-SOCKET HEAD (M5X0.8X20-MM) | 2 | |
| 6V5215 | 39 BOLT (M8X1.25X16-MM) | 2 | |
| 4F7952 | 40 SEAL-O-RING | 1 |
