2W-4908 CLUTCH GPS/N BDN1-UP

Group No: 2W-4908

Part Number	Part Name	Qty
4B4810	1 LEVER AS-HAND	1
0S1587	BOLT (1/2-13X1.75-IN)	1
6L3969	2 PIN	4
6L3964	PIN-COTTER	8
6L3970	3 PIN	4
3N8427	4 CARRIER AS-BEARING	1
9F2247	PLUG-PIPE (1/8-27-THD)	1
2W4904	5 RING-SEAL	2
5L3495	6 LINK-LEVER	8
2L6010	7 PLUG-PIPE	2
5L1545	8 CUP-BEARING	2
7L6551	CONE-BEARING	2
5L3556	9 SHIM (0.0200-IN THK)	1
5L3557	SHIM (0.010-IN THK)	1
5L3558	SHIM (0.007-IN THK)	1
5L3559	SHIM (0.005-IN THK)	1
5L3613	10 RETAINER-BEARING	1
0S1594	11 BOLT (3/8-16X1-IN)	6
5L3560	PLATE-LOCK	3
5L3553	12 YOKE	1
5L3485	13 SHAFT-CLUTCH LEVER	1
6L5151	KEY-WOODRUFF	2
0S1591	14 BOLT (3/8-16X1.5-IN)	2
3N1462	15 PIN AS	1
3N1461	16 SPRING	1
5L3602	17 PLATE-PRESSURE	1
4P3020	18 PLATE-DRIVE	3
3N9175	19 RING-DRIVE	1
4B4773	20 LOCK	1
4B4764	21 NUT	1
3N9176	22 KEY	1
3N9178	23 PLATE-HUB & BACK	1
5L3603	24 PLATE AS-CENTER	2
6L4016	25 PIN	4
6L3961	26 PIN-COTTER	4
5L3493	27 LEVER	4
5L3492	28 YOKE-ADJUSTMENT	1
5L3496	29 SLEEVE-SLIDING	1
0S1625	30 BOLT (5/8-11X2.5-IN)	8
5L3487	31 COLLAR AS	1
5L3561	31A SHIM (0.06-IN THK)	2
2L6267	31B LOCKNUT (3/8-24-THD)	2
0L1648	31C BOLT (3/8-24X2.5-IN)	2
5B2410	32 HOSE AS	1
3B8489	33 FITTING-GREASE (1/8-27 PTF)(CLUTCH)	2
9S1354	NUT (5/8-18-THD)	1
6F0253	LOCKWASHER	1
1L6931	34 SCREW AS-MACHINE (1/4-20X0.5-IN)	2
1083561	35 PLATE-INSTRUCTION (POWER TAKE-OFF)	1
5L3617	36 SEAL-RUBBER	1
3N9179	37 HOUSING-CLUTCH	1
8B7121	FITTING-HYDRAULIC (CLUTCH)	2
4B9782	38 BALL	1
3N9180	39 SHAFT-CLUTCH	1
5P3499	40 BALL BEARING	1
