System And Components
2W-4912 CLUTCH GPS/N BDN1-UP
Group No: 2W-4912
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1083633 | 1 PLATE-INSTRUCTION (POWER TAKE-OFF) | 1 | |
| 1083560 | 2 PLATE-WARNING (POWER TAKE-OFF) | 1 | |
| 1A1460 | 3 BOLT (1/2-13X2-IN) | 2 | |
| 1B8737 | 4 KEY-WOODRUFF | 2 | |
| 1L6931 | 5 SCREW AS-MACHINE (1/4-20X0.5-IN) | 4 | |
| 2B7408 | 6 PLUG-PIPE | 1 | |
| 2L4437 | 7 LEVER | 4 | |
| 2L4441 | 8 WASHER | 8 | |
| 2L7151 | 9 NUT | 1 | |
| 2L7152 | 10 LOCK | 1 | |
| 2L7153 | 11 KEY | 1 | |
| 2L7154 | 12 PLATE | 1 | |
| 2L7155 | 13 HOUSING-CLUTCH | 1 | |
| 2L7156 | 14 PLATE | 1 | |
| 2L7157 | 15 RETAINER | 1 | |
| 2L7158 | 16 RETAINER | 1 | |
| 2L7159 | 17 RING | 1 | |
| 2L7160 | 18 SLEEVE | 1 | |
| 2L7161 | 19 RING | 1 | |
| 2L7162 | 20 PLATE | 2 | |
| 2L7246 | 21 BEARING-ROLLER | 1 | |
| 3B4506 | 22 LOCKWASHER | 6 | |
| 3B4510 | 23 LOCKWASHER (CLUTCH) | 6 | |
| 3B4615 | 24 PIN-COTTER | 4 | |
| 3B8489 | 25 FITTING-GREASE (1/8-27 PTF) | 2 | |
| 3H9575 | 26 LOCK PIN | 1 | |
| 4B4760 | 27 LINK | 8 | |
| 4B4775 | 28 HOSE AS | 1 | |
| 4L6105 | 29 PLATE-DRIVE | 3 | |
| 4W2655 | 30 LEVER-HAND CONTROL | 1 | |
| 5F0229 | 31 SPRING | 1 | |
| 5L9423 | 32 PLATE-COVER | 1 | |
| 5N1934 | 33 SHAFT-CLUTCH | 1 | |
| 5N8132 | 34 RING-DRIVE | 1 | |
| 6F0253 | 35 LOCKWASHER | 1 | |
| 6F6580 | 36 COLLAR AS-CONE | 1 | |
| 0L1558 | BOLT (1/2-20X3.25-IN) | 2 | |
| 2K0564 | LOCKNUT (1/2-20-THD) | 2 | |
| 4B4723 | SHIM | 2 | |
| 6F6581 | 37 YOKE-CLUTCH | 1 | |
| 6F6582 | 38 SHAFT-OPERATING | 1 | |
| 6L3971 | 39 PIN | 8 | |
| 6L3973 | 40 PIN | 4 | |
| 7J5925 | 41 PIN-COTTER | 8 | |
| 8B7121 | 42 FITTING-HYDRAULIC | 2 | |
| 9B0453 | 43 LOCKWASHER (CLUTCH) | 2 | |
| 9S1354 | 44 NUT (5/8-18-THD) | 1 | |
| 9X8882 | 45 BOLT (5/8-11X2.5-IN) | 6 | |
| 0S1588 | 46 BOLT (3/8-16X1.25-IN) | 6 |
