System And Components
364-7875 CONTROL & LINES GP-RIDES/N WW3583-UP
Group No: 364-7875
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1503055 | 1 CONNECTOR AS | 1 | |
| 1134676 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 2 | |
| 1488355 | 2 ELBOW AS | 1 | |
| 6V9005 | ELBOW | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488357 | 3 ELBOW AS | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 3894235 | 5 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3894340 | 6 MANIFOLD | 1 | |
| 4336044 | 7 HOSE AS | 1 | |
| 4646817 | 9 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4564388 | 10 BRACKET | 1 | |
| 4564389 | 11 BRACKET | 1 | |
| 4782393 | 12 BRACKET AS | 1 | |
| 9C4935 | PLATE | 1 | |
| 1P3702 | 13 SEAL-RECTANGULAR | 1 | |
| 5P1076 | 14 WASHER-HARD (13.5X30X4-MM THK) | 10 | |
| 5P7468 | 15 CLIP (SLOT) | 1 | |
| 5P7469 | 16 CLIP (TAB) | 1 | |
| 8T2525 | 17 GROMMET | 1 | |
| 7X7729 | 19 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 21 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4139 | 22 BOLT (M12X1.75X30-MM) | 3 | |
| 8T4172 | 23 BOLT (M10X1.5X80-MM) | 4 | |
| 8T4183 | 24 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4192 | 25 BOLT (M12X1.75X25-MM) | 10 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 5778810 | 27 ACCUMULATOR GP-RIDE CONTROL (CHARGED)(BOTTOM) | 1 | |
| 5778806 | 28 ACCUMULATOR GP-RIDE CONTROL (CHARGED)(TOP) | 1 |
