System And Components
576-1587 WIRING GP-CONSOLE -CANOPY, 2-POSTS/N RHM1-1686
Group No: 576-1587
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4191 | 1 BOLT (M10X1.5X16-MM) | 1 | |
| 3S2093 | 2 STRAP-CABLE | 15 | |
| 1622165 | 3 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 3 | |
| 7K1181 | 4 STRAP-CABLE | 31 | |
| 7P1695 | 5 WASHER (10.5X19X3-MM THK) | 1 | |
| 8T4121 | 6 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T8894 | 7 BOLT-SOCKET HEAD (M10X1.5X20-MM) | 1 | |
| 0966166 | 8 WASHER-HARD (4.5X9X1-MM THK) | 3 | |
| 1138490 | 9 FUSE (10-AMPERE) | 1 | |
| 1138491 | 10 FUSE (15-AMPERE) | 1 | |
| 1138492 | 11 FUSE (20-AMPERE) | 1 | |
| 1167471 | 12 PULLER-MINIFUSE | 1 | |
| 1243548 | 13 FUSE (30-AMPERE) | 1 | |
| 2667379 | 14 STRAP-CABLE | 1 | |
| 2980663 | 15 CLIP (LADDER) | 1 | |
| 3260372 | 16 HOLDER | 1 | |
| 4362988 | 17 ACTUATOR (MAGNETIC) | 1 | |
| 1325789 | 18 CLIP (LADDER) | 2 | |
| 2061345 | 19 STRAP-CABLE | 1 | |
| 3169351 | 20 MOUNTING-CABLE TIE | 1 | |
| 3781007 | 21 SWITCH AS-MAGNETIC (PROXIMITY)(HYDRAULIC LOCKOUT) | 1 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 1710596 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 1028803 | 22 KIT-RECEPTACLE (3-PIN) | 1 | |
| 3T0851 | 23 LOCKNUT (M5X0.8-THD) | 1 | |
| 4279771 | 24 TIE | 1 | |
| 4I3038 | 25 WASHER (3.3X8X0.5-MM THK) | 2 | |
| 4P7581 | 26 CLIP (LADDER) | 2 | |
| 5140566 | 27 MONITOR-DISPLAY | 1 | |
| 5428879 | 28 HARNESS AS-SENSOR (LH) | 1 | |
| 5761579 | 29 HARNESS AS-CHASSIS (RH) | 1 | |
| 5761581 | 30 HARNESS AS-CHASSIS (CENTER) | 1 | |
| 5807151 | 31 HARNESS AS-MONITOR (CANOPY) | 1 | |
| 6V9671 | 32 SCREW-MACHINE (M3X0.5X12-MM) | 1 | |
| 8T0328 | 33 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8T2658 | 34 LOCKNUT (M3X0.5-THD) | 1 | |
| 8C4982 | 35 BOLT-SOCKET HEAD (M4X0.7X20-MM) | 2 | |
| 8T4137 | 36 BOLT (M10X1.5X20-MM) | 2 | |
| 8T8737 | 37 PLUG-SEAL | 3 | |
| 5872287 | 38 SPACER | 1 |
