System And Components
556-7952 WIRING GP-CHASSISS/N FEY10101-UP
Group No: 556-7952 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0874587 | 1 GROMMET | 1 | |
| 0919035 | 2 SPACER (11X25X20-MM THK) | 2 | |
| 1114836 | 3 CLIP | 10 | |
| 1114837 | 4 CLIP | 7 | |
| 1114838 | 5 CLIP | 11 | |
| 1114839 | 6 STRAP | 11 | |
| 1160118 | 7 CLIP | 6 | |
| 1325789 | 8 CLIP (LADDER) | 8 | |
| 1343355 | 9 STRAP AS | 1 | |
| 1709328 | 10 STRAP AS-GROUND | 1 | |
| 1709360 | 11 GROMMET | 1 | |
| 1772215 | 12 STRAP-DUAL CLAMP | 1 | |
| 2595317 | 13 BRACKET AS | 1 | |
| 1831051 | CLIP | 6 | |
| 2667379 | 14 STRAP-CABLE | 1 | |
| 2917593 | 15 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2G8767 | 16 WASHER (10.5X60X3-MM THK) | 3 | |
| 3068401 | 17 GROMMET (85-MM ID) | 1 | |
| 3181181 | 18 SENSOR GP-SPEED (MAGNETIC) | 1 | |
| 3474734 | 19 CLIP | 1 | |
| 3778051 | 20 BRACKET AS (ENGINE) | 1 | |
| 1831051 | CLIP | 2 | |
| 7T1099 | LINK | 1 | |
| 3990797 | 21 BRACKET AS (ENGINE) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3S2093 | 22 STRAP-CABLE | 39 | |
| 4I7889 | 23 SPACER (11X25X45-MM THK) | 4 | |
| 4K8864 | 24 CLIP (LOOP) | 1 | |
| 4P7428 | 25 CLIP (LADDER) | 1 | |
| 4P7581 | 26 CLIP (LADDER) | 4 | |
| 5567955 | 27 CABLE AS-STARTER | 1 | |
| 6V2722 | TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M) | ||
| 9X9825 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 0301705 | TERMINAL-CABLE (00-GA, 5/16-IN SCREW) | 1 | |
| 1598049 | CABLE (00-GA, RED)(255-CM) | ||
| 2761786 | COVER-TERMINAL (RED) | 1 | |
| 5567960 | 28 CABLE AS-GROUND | 1 | |
| 3116184 | TERMINAL-RING (2-GA, 3/8-IN SCREW) | 1 | |
| 5613043 | 29 BRACKET AS | 1 | |
| 1787023 | BOSS (M10X1.5X30-MM) | 1 | |
| 2944550 | BOSS-WELD (M10X1.5X60-MM) | 1 | |
| 5631443 | 30 BRACKET AS | 1 | |
| 7T1099 | LINK | 2 | |
| 5807616 | 31 HARNESS AS-CHASSIS | 1 | |
| 5I3878 | 32 GROMMET (50-MM ID) | 1 | |
| 5P4116 | 33 WASHER-HARD (8.8X20.5X2-MM THK) | 3 | |
| 6G2256 | 34 CLAMP | 2 | |
| 6G2263 | 35 SPACER (10.5X19X28.5-MM THK) | 4 | |
| 6K8178 | 36 CLIP (LOOP) | 3 | |
| 7I2673 | 37 STRAP-CABLE | 4 | |
| 7K1181 | 38 STRAP-CABLE | 16 | |
| 7X2621 | 39 BOLT (M10X1.5X12-MM) | 1 | |
| 7Y8165 | 40 GROMMET | 1 | |
| 7Y8167 | 41 GROMMET (50-MM ID) | 1 | |
| 8T4121 | 42 WASHER-HARD (11X21X2.5-MM THK) | 62 | |
| 8T4136 | 43 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4137 | 44 BOLT (M10X1.5X20-MM) | 36 | |
| 8T4182 | 45 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4185 | 46 BOLT (M10X1.5X50-MM) | 3 | |
| 8T4186 | 47 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4189 | 48 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4191 | 49 BOLT (M10X1.5X16-MM) | 1 | |
| 8T4195 | 50 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4224 | 51 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T5005 | 52 BOLT (M10X1.5X70-MM) | 1 | |
| 8T6466 | 53 BOLT (M10X1.5X60-MM) | 1 | |
| 8T6869 | 54 BOLT (M8X1.25X60-MM) | 3 |
