System And Components
272-3365 LIGHTING GP-SIGNAL -FENDER, LHS/N LTZ148-UP
Group No: 272-3365
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 3 | |
| 1243019 | 2 BRACKET AS | 3 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1925624 | 3 BRACKET AS | 1 | |
| 2048000 | 4 MOUNTING-CABLE TIE | 33 | |
| 2263492 | 5 BRACKET AS | 1 | |
| 2830657 | 6 CABLE AS (VIDEO, 3-M) | 1 | |
| 3345409 | 7 LAMP GP-SIGNAL (24-VOLT, PARK, TURN)(LH) | 3 | |
| 3524202 | 10 STRAP-CABLE | 2 | |
| 4625945 | 11 BRACKET | 1 | |
| 4792171 | 12 BOLT AS | 13 | |
| 4792172 | 13 BOLT AS | 1 | |
| 4834287 | 14 PLATE | 6 | |
| 4883974 | 15 BOLT AS | 1 | |
| 5287137 | 16 HARNESS AS-LIGHTING (FENDER, LH) | 1 | |
| 1566175 | 17 CLIP (LADDER) | 3 | |
| 1M4543 | 18 GROMMET | 2 | |
| 1V6688 | 19 GROMMET | 1 | |
| 2042281 | 20 STRAP-CABLE | 41 | |
| 2307732 | 21 MOUNTING-CABLE TIE | 1 | |
| 2310336 | 22 STUD-TAPERLOCK (M10X1.5X70-MM) | 7 | |
| 2597140 | 23 STUD-TAPERLOCK (M10X1.5X80-MM) | 1 | |
| 2884402 | 24 STUD-TAPERLOCK (M10X1.5X60-MM) | 1 | |
| 3091905 | 25 STUD-TAPERLOCK (M10X1.5X100-MM) | 4 | |
| 3445673 | 26 NUT (M6X1-THD) | 9 | |
| 3445675 | 27 NUT (M10X1.5-THD) | 13 | |
| 3D6209 | 28 GROMMET | 1 | |
| 1997854 | 29 SPACER (11.8X20X45-MM THK) | 1 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 15 | |
| 8T4137 | 31 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4192 | 33 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4185 | 34 BOLT (M10X1.5X50-MM) | 1 | |
| 8T4205 | 35 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 8T4223 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 1984777 | 37 WASHER-HARD (11X25X10-MM THK) | 1 |
