464-1856 WIRING GP-CHASSISS/N LTZ161-UP

Group No: 464-1856

Part Number	Part Name	Qty
4242325	1 BLOCK	1
4242331	2 BLOCK	8
4242335	3 BLOCK	8
2830659	4 CABLE AS-COAXIAL	1
4242342	5 BLOCK	8
1220450	6 GROMMET	1
1336934	7 SPACER (11X20X25-MM THK)	1
1342252	8 SENSOR GP-TEMPERATURE (8-VOLT)(FRONT BRAKE OIL, RH)	1
2042281	9 STRAP-CABLE	47
2147568	10 SEAL-O-RING	3
2385079	11 SEAL-O-RING	2
2532673	12 SWITCH GP-PRESSURE (BRAKE FILTER)	1
2532673	12A SWITCH GP-PRESSURE (CASE DRAIN FILTER)	1
3J1907	SEAL-O-RING	1
5F9144	SEAL-O-RING	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
9X1813	SLEEVE (14-CM)
1028802	KIT-RECEPTACLE (2-PIN)	1
2597140	13 STUD-TAPERLOCK (M10X1.5X80-MM)	3
2812592	14 PIN-TAPERLOCK	2
3091905	15 STUD-TAPERLOCK (M10X1.5X100-MM)	1
5P5644	16 TRIM (0.2-M EACH)
2922893	17 CONDUIT (10.1-MM ID)(11-CM)
3445675	18 NUT (M10X1.5-THD)	12
3453753	19 MOUNTING-CABLE TIE	6
3524204	20 STRAP-CABLE	2
5286323	21 HARNESS AS-CHASSIS	1
4242345	22 PLATE AS	5
4242359	BOSS	2
4242347	23 PLATE	7
4242350	24 PLATE AS	1
4242359	BOSS	2
2884402	25 STUD-TAPERLOCK (M10X1.5X60-MM)	6
2048000	26 MOUNTING-CABLE TIE	28
4242352	27 PLATE	1
9X7345	28 GROMMET	1
8T4223	29 WASHER-HARD (13.5X25.5X3-MM THK)	1
8T4179	30 BOLT (M12X1.75X20-MM)	1
4704908	31 PLATE	1
4704909	32 PLATE	1
4792171	33 BOLT AS	29
4792172	34 BOLT AS	10
4834287	35 PLATE	3
4877892	36 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
1984780	WASHER-HARD (17.5X32X8-MM THK)	2
4877901	37 GUARD	1
4877902	38 BRACKET	1
4J6304	39 TAG-IDENTIFICATION (NUMBER FOUR)	1
5722633	40 PLATE AS	2
4242359	BOSS	2
5P7468	41 CLIP (SLOT)	4
5P7469	42 CLIP (TAB)	4
5P8444	43 GROMMET (37-MM ID)	4
6V0545	44 GROMMET	2
7K1181	45 STRAP-CABLE	3
8T1897	46 CLIP (SLOT)	1
8T1898	47 CLIP (TAB)	1
8T1899	48 CLIP (SLOT)	1
8T1900	49 CLIP (TAB)	1
8T2920	50 GROMMET (27-MM ID)	1
8T4121	51 WASHER-HARD (11X21X2.5-MM THK)	12
