277-3338 WIRING GP-LUBRICATIONS/N LTZ1-145

Group No: 277-3338

Part Number	Part Name	Qty
7K1181	1 STRAP-CABLE	5
1712215	2 CIRCUIT BREAKER AS (150-AMPERE)	2
1H3244	LOCKWASHER	2
4E5724	WASHER (7X12X1-MM THK)	2
8T0122	NUT-FULL (1/4-28-THD)	2
3155389	3 NUT (M32X1.5-THD)	1
3379078	4 SWITCH GP-MAGNETIC (24-VOLT TO 32-VOLT)	1
3407166	5 CABLE AS	1
6V2722	TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M)
3L6513	TERMINAL-RING (1-GA TO 2-GA, 1/2-IN SCREW)	2
8C0596	CABLE (2-GA)(30-CM)
3785526	6 FILM-IDENTIFICATION (CIRCUIT BREAKER)	2
3911324	7 COVER-TERMINAL	1
4246619	8 BLOCK AS-JUNCTION	1
4254614	9 PLATE	1
4792171	10 BOLT AS	9
4792172	11 BOLT AS	1
4834287	12 PLATE	1
5195773	13 CABLE AS	1
3L6513	TERMINAL-RING (1-GA TO 2-GA, 1/2-IN SCREW)	1
8C3056	CABLE (2-GA, RED)(62-CM)
0301712	TERMINAL-RING (2-GA, 1/4-IN SCREW)	1
3088161	COVER-TERMINAL	1
3260773	SEAL-O-RING	1
5442819	14 CABLE AS	1
3L6513	TERMINAL-RING (1-GA TO 2-GA, 1/2-IN SCREW)	1
8C3056	CABLE (2-GA, RED)(36-CM)
3088161	COVER-TERMINAL	2
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
3116184	TERMINAL-RING (2-GA, 3/8-IN SCREW)	1
5442820	15 CABLE AS	1
3L6513	TERMINAL-RING (1-GA TO 2-GA, 1/2-IN SCREW)	1
8C3056	CABLE (2-GA, RED)(88-CM)
1P0810	TAPE-ELECTRICAL
3088161	COVER-TERMINAL	2
1257876	TUBE-HEAT SHRINK (17.78-MM DIA)(4-CM)
3116184	TERMINAL-RING (2-GA, 3/8-IN SCREW)	1
5442821	16 BRACKET AS	1
5442822	17 BRACKET	1
5442823	18 HARNESS AS-WIRING (PRELUBRICATION)	1
1336934	19 SPACER (11X20X25-MM THK)	1
1774562	20 GROMMET	5
2042281	21 STRAP-CABLE	1
2884402	22 STUD-TAPERLOCK (M10X1.5X60-MM)	2
3293356	23 NUT (M12X1.75-THD)	2
3445675	24 NUT (M10X1.5-THD)	2
3537956	25 GROMMET	2
5C9553	26 BOLT (M6X1X16-MM)	4
6V7978	27 SCREW-MACHINE (10-32X0.375-IN)	4
8T1889	28 CLIP (SLOT)	5
8T1890	29 CLIP (TAB)	5
8T1893	30 CLIP (SLOT)	2
8T1894	31 CLIP (TAB)	2
8T4121	32 WASHER-HARD (11X21X2.5-MM THK)	5
8T4137	33 BOLT (M10X1.5X20-MM)	2
8T4179	34 BOLT (M12X1.75X20-MM)	1
8T4182	35 BOLT (M10X1.5X45-MM)	1
8T4223	36 WASHER-HARD (13.5X25.5X3-MM THK)	3
9X8256	37 WASHER (6.6X12X2-MM THK)	4
