System And Components
293-5065 MOUNTING GP-TRUCK BODYS/N LTZ1-UP
Group No: 293-5065
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5T7352 | 1 STRIP | 3 | |
| 1475072 | 2 PLATE | 12 | |
| 1475073 | 3 SHIM (2-MM THK) | 54 | |
| 1475075 | 4 PAD AS | 2 | |
| 1491926 | 5 PLATE | 4 | |
| 1494621 | 6 GUIDE AS | 2 | |
| 1541808 | 7 PLATE | 10 | |
| 1735403 | 8 PAD AS | 10 | |
| 1754935 | 9 EJECTOR AS | 2 | |
| 2195893 | 10 CLEVIS | 2 | |
| 2365558 | 11 PLATE AS | 2 | |
| 5268424 | 11A BEARING-SLEEVE | 2 | |
| 2956901 | 12 PLATE | 4 | |
| 2956917 | 13 PIN AS | 2 | |
| 3360743 | 14 CABLE AS | 2 | |
| 4808667 | 15 MUD FLAP | 3 | |
| 5071577 | 16 SHOE AS | 2 | |
| 5189364 | 17 PIN | 2 | |
| 1856715 | 18 PIN | 2 | |
| 3B4647 | 19 PIN-COTTER | 4 | |
| 3D0404 | 20 WASHER (1.781X3.25X0.25-IN THK) | 2 | |
| 6V7744 | 21 LOCKNUT (M10X1.5-THD) | 36 | |
| 7D1649 | 22 WASHER-HARD (13.5X32X5-MM THK) | 36 | |
| 7X2553 | 23 BOLT (M16X2X40-MM) | 16 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 72 | |
| 8T4184 | 25 BOLT (M12X1.75X45-MM) | 6 | |
| 8T4192 | 26 BOLT (M12X1.75X25-MM) | 8 | |
| 8T4196 | 27 BOLT (M10X1.5X35-MM) | 36 | |
| 8T4244 | 28 NUT (M12X1.75-THD) | 30 | |
| 8T4910 | 29 BOLT (M12X1.75X60-MM) | 30 | |
| 9X8257 | 30 WASHER (17.5X30X3.5-MM THK) | 16 |
