579-0326 CONTROL GP-MACHINES/N ST71-402

Group No: 579-0326

Part Number	Part Name	Qty
5214488	1 PANEL-DASH	1
1781628	2 INSERT-THREADED (1/4-20-THD)	4
6D3033	3 SCREW-SOCKET HEAD (4-40X0.5-IN)	4
1172311	4 SOCKET-AUXILIARY POWER (12-VOLT)	2
1364837	5 CONTROL GP-HOIST ELECTRONIC	1
1400386	6 COVER	1
2292580	7 SWITCH AS-ROCKER (24-VOLT)(THROTTLE LOCK)	1
4316106	8 BRACKET AS	1
6V9632	NUT-WELD (M6X1-THD)	3
4318431	9 SWITCH-ROCKER (ON/OFF)	1
4322938	10 PANEL-DASH (LH)	1
4322979	11 SWITCH AS-PUSH BUTTON (AUTOMATIC RETARDER ON, OFF)	1
1790608	BLOCK-CONTACT	2
1790609	BLOCK-CONTACT	2
4322980	12 SWITCH-ROCKER (AUTOMATIC RETARDER CONTROL)	1
4322981	13 SWITCH (ACTUATOR)	1
4329158	14 SWITCH (LIGHT TEST)	1
4329191	15 SWITCH-ROCKER (ON, OFF)	2
4329192	16 SWITCH-ROCKER (BASE)	1
4329193	17 SWITCH (STAIRWAY LIGHTS)	1
4329195	18 SWITCH (AUTOLUBE)	1
4329211	19 SWITCH (ALARM, AUTOLUBE)	1
4329215	20 SWITCH AS-PUSH BUTTON (BRAKE)	1
4547864	BLOCK AS	1
4547865	KNOB	1
4547866	BLOCK	1
4547867	LENS-AMBER	1
2N3680	21 SCREW-HEAD (1/4-20X0.75-IN)	20
4567679	22 HARNESS AS-CONTROL	1
4638404	23 FITTING	4
2286089	24 PLUG (ROCKER SWITCH)	1
1092356	25 PLUG	7
2552752	26 SWITCH GP-START (IGNITION)	1
2848905	27 CONTROL GP-UNPRGMED MONITOR (ADVISOR)	1
3445674	28 NUT (M8X1.25-THD)	2
5196518	29 BRACKET	2
3S2093	30 STRAP-CABLE	4
4195974	31 ADAPTER AS (AT04-6P TO RJ45)	1
4322668	NUT (13/16-28-THD)	1
4318456	32 INDICATOR-RESTRICTION (AIR FILTER)	4
4322939	33 PANEL GP-INSTRUMENT (CENTER)	1
4329169	34 INDICATOR (STEERING PRESSURE)	1
4329170	35 INDICATOR (FUEL LEVEL)	1
4329171	36 INDICATOR (TRANSMISSION OIL TEMPERATURE)	1
4329172	37 INDICATOR (PARKING BRAKE OIL PRESSURE)	1
4329173	38 INDICATOR (CHECK ENGINE)	1
4329174	39 INDICATOR (ELECTRICAL FAULT)	2
4329175	40 INDICATOR (HYDRAULIC OIL TEMPERATURE)	1
4329176	41 INDICATOR (ENGINE STOP)	1
4329177	42 INDICATOR (HYDRAULIC OIL LEVEL)	1
4329178	43 INDICATOR (TEST)	1
4329190	44 PLATE	2
4329194	45 SWITCH (HEADLIGHTS, TAIL LIGHTS)	1
4329196	46 LIGHT-INDICATOR (24-VOLT)	7
4329197	47 LIGHT-INDICATOR (24-VOLT)	9
4329198	48 PLUG-BEZEL	8
4329203	49 INDICATOR (BRAKE, FRONT)	1
4329204	50 INDICATOR (BRAKE, REAR)	1
4329210	51 INDICATOR (AUTOLUBE)	1
4329216	52 PLUG-BEZEL	4
4329217	53 INDICATOR (RETARDANT)	1
5Y0974	54 SCREW-BUTTON HEAD (1/4-20X0.5-IN)	4
4798151	55 CONTROL GP-TRANSMISSION	1
5209187	56 INDICATOR (TRACTION CONTROL)	1
4L6454	57 BOLT (3/8-16X1-IN)	3
4M5281	58 BOLT (1/4-20X0.75-IN)	2
5270345	59 FILM-IDENTIFICATION (PORT)	1
5713984	60 PANEL AS-CONSOLE	1
0083131	TERMINAL	2
4329256	CONNECTOR	1
4538574	KIT-WIRING (INVERTER)	1
5P5942	SEAL (2-M)
5214493	61 BRACKET	1
5757093	62 BRACKET	1
5B3254	63 NUT-JAM (7/16-20-THD)	4
5C9553	64 BOLT (M6X1X16-MM)	6
5P4115	65 WASHER-HARD (7.2X19X2-MM THK)	8
5P4116	66 WASHER-HARD (8.8X20.5X2-MM THK)	2
5P6941	67 CONNECTOR	4
5797008	68 FILM-INSTRUCTION (RETARDING GUIDELINES, READ OMM)	1
2Q7924	69 LIGHT-INDICATOR (24-VOLT)	1
5846435	70 COVER AS-LIGHT	1
5S7349	71 BOLT (1/4-20X0.5-IN)	4
6B4540	72 NUT (4-40-THD)	4
6V8801	73 NUT (3/8-16-THD)	3
6V9497	74 WASHER-HARD (3.2X6X0.5-MM THK)	8
8M2770	75 CLIP (LOOP)	2
8T4205	76 WASHER-HARD (7.2X14.5X2-MM THK)	2
8T4896	77 WASHER-HARD (10.2X18.5X2.5-MM THK)	2
9P6571	78 PLUG	1
9X2038	79 WASHER (7X19X2-MM THK)	8
9X2045	80 SCREW-TRUSS HEAD (M6X1X20-MM)	3
1440195	81 HOSE (295-CM)
1440195	81A HOSE (313-CM)
1440195	81B HOSE (284-CM)
1440195	81C HOSE (277-CM)
4538574	KIT-WIRING (INVERTER)	1
