493-8265 AIR CONDITIONER GPS/N ST71-UP

Group No: 493-8265

Part Number	Part Name	Qty
2756710	1 RETAINER (PUSH ON)	2
2U0708	2 FITTING-BULKHEAD	2
6K8420	3 LOCKNUT (1-1/16-12-THD)	2
2883657	4 SCREW-THUMB (M6X1X10-MM)	2
2656619	5 FILTER ELEMENT-CAB AIR (FRESH AIR)	1
3810212	6 CLAMP-HOSE	7
4322892	7 WHEEL	2
4322895	8 CORE-HEATER	1
4322897	9 CLIP	4
4322899	10 ADAPTER	2
3S8664	11 CLIP	1
4177951	12 FILTER-AIR (HEATER)	1
4329955	13 ELBOW	2
4322916	14 RESISTOR	4
2U2065	15 CONNECTOR	2
4657630	16 ACTUATOR & VALVE GP-HTR CONT	1
4322922	17 GROMMET	1
4322923	18 VALVE (EXPANSION)	1
4792171	19 BOLT AS	2
4323516	20 SEAL-O-RING	2
4F7957	21 BOLT (1/4-20X0.875-IN)	2
4329956	22 BUSHING-PIPE	2
4548915	23 RING	2
4M5281	24 BOLT (1/4-20X0.75-IN)	10
5752609	25 BRACKET AS	1
7X7729	WASHER (11X25X3-MM THK)	1
8T3490	NUT-WELD (M10X1.5-THD)	1
9R3761	BOSS (M10X1.5X51-MM)	1
4937744	26 BOX AS	1
2D6235	LOCKNUT (1/4-20-THD)	12
6V9632	NUT-WELD (M6X1-THD)	2
4937745	27 PLATE-MOTOR	2
4937746	28 HOUSING-BLOWER	2
4937748	29 MOTOR	2
4944369	30 COIL-EVAPORATOR	1
4946523	31 COVER-FILTER	1
5P7162	32 SCREW-MACHINE (10-32X0.5-IN)	20
6D4246	33 CLIP (LOOP)	4
6V8378	34 NUT (10-32-THD)	4
7X0579	35 WASHER-HARD (8.8X25.5X2-MM THK)	12
9S8896	36 CAP (FLARED 37-DEG)	2
9X2185	37 SCREW (8-15X0.44-IN)	4
9X8250	38 CLIP (LOOP)	1
5P0767	39 HOSE (20-CM)
9X2133	40 HOSE (305-CM)
5P1680	41 HOSE (10-CM EACH)
5P7070	42 INSULATION-STRIP (0.3-M)
6V2495	43 SEAL (1.2-M)
8T6936	44 SEAL (1.2-M)
