System And Components
520-9587 LINER GP-CABS/N N941-UP
Group No: 520-9587
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X7877 | 1 STRIP-EDGE (4-CM) | ||
| 3962352 | 2 LOUVER AS | 2 | |
| 1005612 | 3 FILM-INSTRUCTION (ALTERNATE EXIT, REMOVE WINDOW) | 1 | |
| 1013055 | 4 COVER-SPEAKER | 2 | |
| 1039425 | 5 SCREW-MACHINE (8-32X1-IN) | 8 | |
| 1042091 | 6 SCREW-FLAT HEAD (6-20X0.5-IN) | 20 | |
| 1064496 | 7 BRACKET AS | 6 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 1114627 | 8 SCREW-MACHINE (M6X1X30-MM) | 2 | |
| 1219870 | 9 SCREW-MACHINE (M6X1X40-MM) | 4 | |
| 1265211 | 10 SPACER (3X15X17-MM THK) | 2 | |
| 1293178 | 11 LOCKNUT (M6X1-THD) | 3 | |
| 1316009 | 12 PIN | 2 | |
| 1692876 | 13 FILM-IDENTIFICATION (POWER RECEPTACLE, 12-VOLT) | 1 | |
| 2008623 | 14 NUT-RETAINER | 8 | |
| 2253109 | 15 SCREW-TRUSS HEAD (M4X0.7X14-MM) | 2 | |
| 2286089 | 16 PLUG (ROCKER SWITCH) | 5 | |
| 2364631 | 17 BEZEL | 7 | |
| 2G8572 | 18 WASHER-SPECIAL | 1 | |
| 2G8573 | 19 CAP | 1 | |
| 2V3726 | 20 BUMPER | 1 | |
| 3313892 | 21 FILM-INSTRUCTION (WASHER FILL) | 1 | |
| 3734446 | 22 PLUG | 1 | |
| 3G3265 | 23 RIVET | 24 | |
| 3T0852 | 24 LOCKNUT (M8X1.25-THD) | 2 | |
| 4222152 | 25 LOUVER AS-VENT | 10 | |
| 5125956 | 26 DUCT | 1 | |
| 5125957 | 27 DUCT | 1 | |
| 5125959 | 28 HEADLINER | 1 | |
| 5125961 | 29 DOOR | 2 | |
| 5125962 | 30 PANEL | 1 | |
| 5125964 | 31 PANEL | 1 | |
| 5125965 | 32 COVER (RH) | 1 | |
| 5125966 | 33 COVER (LH) | 1 | |
| 5125967 | 34 COVER (RH) | 1 | |
| 5125968 | 35 COVER (LH) | 1 | |
| 6V5163 | 36 SEAL (1.1-M) | ||
| 6V5163 | 36A SEAL (1.3-M) | ||
| 5125976 | 37 PANEL | 1 | |
| 5125979 | 38 COVER (RH) | 1 | |
| 5125983 | 39 PANEL AS | 1 | |
| 7K4201 | NUT-SPEED | 2 | |
| 5129033 | 40 PLATE | 1 | |
| 5129034 | 41 PLATE | 1 | |
| 5129047 | 42 PLATE | 1 | |
| 5167916 | 43 PLATE | 1 | |
| 5183032 | 44 PLATE AS | 1 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 2 | |
| 5215517 | 45 DUCT AS | 1 | |
| 5215524 | 46 PLATE AS | 2 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 5239067 | 47 PANEL | 1 | |
| 8T3426 | 48 CHANNEL-TRIM (1.5-M) | ||
| 5335743 | 49 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 5C2890 | 50 NUT (M6X1-THD) | 2 | |
| 5P4115 | 51 WASHER-HARD (7.2X19X2-MM THK) | 4 | |
| 6G2395 | 52 DOOR GP (AIR VENTED) | 2 | |
| 6G7222 | ROLLER | 2 | |
| 6G2396 | 53 GASKET | 2 | |
| 6G2751 | 54 HINGE | 4 | |
| 6G2914 | 55 LATCH (SPRING) | 2 | |
| 6K3273 | 56 RIVET-POP | 8 | |
| 6P0205 | 57 SPACER (0.269X0.405X0.656-IN THK) | 3 | |
| 6V0292 | 58 PLUG | 1 | |
| 6V3928 | 59 PLUG-BUTTON | 1 | |
| 6V8928 | 60 HOOK-COAT | 1 | |
| 7G4824 | 61 STRAP | 1 | |
| 7X0579 | 62 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 8C9660 | 63 WASHER (4.6X7.9X0.8-MM THK) | 6 | |
| 8E7791 | 64 STRAP | 1 | |
| 8F0492 | 65 SPACER (0.531X1.125X0.625-IN THK) | 1 | |
| 8T4121 | 66 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4182 | 67 BOLT (M10X1.5X45-MM) | 2 | |
| 8T4195 | 68 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4224 | 69 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4896 | 70 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T5401 | 71 PLUG-BUTTON | 2 | |
| 8X5102 | 72 SEAL | 1 | |
| 8X5414 | 73 PLATE | 1 | |
| 8Y6379 | 74 KIT-HAMMER (CAB WINDOW) | 1 | |
| 9N1995 | 75 RIVET-POP | 20 | |
| 9R5616 | 76 PLUG | 2 | |
| 9X2041 | 77 SCREW-TRUSS HEAD (M10X1.5X20-MM) | 4 | |
| 9X2042 | 78 SCREW-TRUSS HEAD (M6X1X12-MM) | 8 | |
| 9X2043 | 79 SCREW-TRUSS HEAD (M6X1X14-MM) | 37 | |
| 9X2045 | 80 SCREW-TRUSS HEAD (M6X1X20-MM) | 16 | |
| 9X2046 | 81 SCREW-TRUSS HEAD (M6X1X35-MM) | 4 | |
| 9X8256 | 82 WASHER (6.6X12X2-MM THK) | 7 |
