System And Components
107-0545 VALVE GP-CONTROL -RIPPERS/N N951-UP
Group No: 107-0545
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6E4599 | 1 BODY | 1 | |
| 1011148 | 2 STEM | 1 | |
| 1011978 | 3 COVER | 1 | |
| 2K8199 | 4 SEAL-O-RING | 2 | |
| 8T4189 | 5 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4224 | 6 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 1011984 | 7 BODY | 1 | |
| 3549444 | 8 VALVE GP-CHECK | 2 | |
| 6E3013 | SEAT | 1 | |
| 1398472 | 9 VALVE GP-RELIEF (RIPPER) | 1 | |
| 1027412 | 11 SPRING | 1 | |
| 1011973 | 12 RETAINER | 4 | |
| 1011971 | 13 LEVER | 1 | |
| 3405472 | 14 LEVER AS (LH) | 1 | |
| 8M4437 | 15 SEAL-O-RING | 2 | |
| 4D9986 | 17 SEAL-O-RING | 1 | |
| 1012480 | 18 COVER | 1 | |
| 8T4138 | 19 BOLT (M6X1X20-MM) | 2 | |
| 5B9318 | 20 BALL | 1 | |
| 6E3007 | 21 SPRING | 1 | |
| 6E4502 | 22 PLUG | 1 | |
| 4J7533 | 23 SEAL-O-RING | 1 | |
| 6E3019 | 24 VALVE | 1 | |
| 6E5153 | 25 SPRING | 1 | |
| 1082187 | 26 PLUG-PIPE | 1 | |
| 1488395 | 29 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 1063659 | 31 PISTON | 1 | |
| 1118233 | 34 SPRING | 1 | |
| 3K0360 | 35 SEAL-O-RING | 2 | |
| 9J0403 | 36 SPRING | 2 | |
| 9J0404 | 37 PLUG | 2 | |
| 3613549 | 38 SEAL-O-RING | 2 |
