System And Components
487-6223 PUMP GP-PISTONPART OF 515-0453 PUMP & MTG GP-MAIN HYDRAULIC
Group No: 487-6223
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5734321 | 1 VALVE GP-PUMP CONTROL (PRESSURE) | 1 | |
| 1683504 | 2 SEAL | 2 | |
| 1401739 | 3 RING-RETAINING | 1 | |
| 2472852 | 4 STOP | 1 | |
| 2470478 | 5 SPRING | 1 | |
| 3795187 | 6 SPRING | 1 | |
| 3337840 | 7 STOP | 1 | |
| 6V8201 | 8 BOLT-SOCKET HEAD (M16X2X45-MM) | 4 | |
| 0834419 | 9 PIN | 1 | |
| 1053032 | 10 CONE-BEARING | 1 | |
| 1053033 | 11 CUP-BEARING | 1 | |
| 4908784 | 12 SEAL-O-RING | 1 | |
| 1051638 | 13 SPACER (30X38X3-MM THK) | 1 | |
| 4930906 | 14 SWASHPLATE | 1 | |
| 3891201 | 15 ROTATING GP-PUMP | 1 | |
| 1053031 | 16 CONE-BEARING | 1 | |
| 3B2263 | 17 CUP-BEARING | 1 | |
| 3996708 | 18 SHAFT-DRIVE | 1 | |
| 1338739 | 19 SEAL-LIP TYPE | 1 | |
| 5413452 | 20 SHELL-BEARING | 2 | |
| 3603167 | 21 PLATE-CONTROL | 1 | |
| 6R7943 | 22 SCREW (M5X0.8X15-MM) | 2 | |
| 5834759 | 23 VALVE GP-SERVO (VARIABLE DISPLACEMENT) | 1 | |
| 2287106 | SEAL-O-RING | 1 | |
| 4876236 | 24 CONTROL-VALVE | 1 |
