System And Components
490-2604 WIRING GP-CAB -MAIN CABS/N Y9A1-UP
Group No: 490-2604
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1693145 | 1 WIRE AS | 1 | |
| 3E0105 | 2 MOUNT | 1 | |
| 3E5239 | 3 RELAY AS (24-VOLT)(CAB, INDICATOR LAMP) | 1 | |
| 3G1701 | 4 SPRING | 1 | |
| 3S2093 | 5 STRAP-CABLE | 9 | |
| 5T4030 | 6 BRACKET | 1 | |
| 7I4696 | 7 RETAINER | 1 | |
| 7I4699 | 8 INSULATOR | 1 | |
| 7K1181 | 9 STRAP-CABLE | 128 | |
| 7T4003 | 10 RESISTOR | 2 | |
| 8C5607 | 11 MOUNT-ISOLATION | 8 | |
| 0094184 | 12 SPRING-HORN | 4 | |
| 0094185 | 13 BRUSH-HORN | 4 | |
| 0919071 | 14 SEAL-HORN BUTTON | 1 | |
| 0987467 | 15 BUTTON | 1 | |
| 1138490 | 16 FUSE (10-AMPERE) | 15 | |
| 1138491 | 17 FUSE (15-AMPERE) | 16 | |
| 1138492 | 18 FUSE (20-AMPERE) | 2 | |
| 7X7877 | 19 STRIP-EDGE (11.3-CM EACH) | ||
| 7X7877 | 19A STRIP-EDGE (3.8-CM) | ||
| 1794814 | 20 PIN | 3 | |
| 2011024 | 21 BRACKET | 1 | |
| 2284982 | 22 RESISTOR AS | 3 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 2286089 | 23 PLUG (ROCKER SWITCH)(HAZARD LIGHT) | 1 | |
| 2286089 | 23A PLUG (ROCKER SWITCH)(BACKLIGHT) | 1 | |
| 2286089 | 23B PLUG (ROCKER SWITCH)(FLOODLIGHT) | 1 | |
| 2286089 | 23C PLUG (ROCKER SWITCH)(WORK LIGHTS) | 1 | |
| 2286089 | 23D PLUG (ROCKER SWITCH)(HEADLIGHT) | 1 | |
| 2286089 | 23E PLUG (ROCKER SWITCH)(WARNING BEACON) | 1 | |
| 2286089 | 23F PLUG (ROCKER SWITCH)(HVAC) | 1 | |
| 2286089 | 23G PLUG (ROCKER SWITCH)(DEFROST FAN, LH) | 1 | |
| 2286089 | 23H PLUG (ROCKER SWITCH)(DEFROST FAN, RH) | 1 | |
| 2286089 | 23J PLUG (ROCKER SWITCH)(HEATED MIRROR) | 1 | |
| 2286089 | 23K PLUG (ROCKER SWITCH)(SPACER COVER) | 3 | |
| 2366253 | 24 GROMMET | 1 | |
| 2482841 | 25 RELAY AS (24-VOLT)(POSITION LAMP, LH) | 1 | |
| 2482841 | 25A RELAY AS (24-VOLT)(FORWARD HORN) | 1 | |
| 2482841 | 25B RELAY AS (24-VOLT)(POSITION LAMP, RH) | 1 | |
| 2482841 | 25C RELAY AS (24-VOLT)(BLOWER, MEDIUM) | 1 | |
| 2757741 | 26 SWITCH GP-WIPER (24-VOLT)(CAB) | 1 | |
| 3070649 | 27 KNOB | 1 | |
| 3259407 | 28 FILM-IDENTIFICATION (WRITE DATA) | 1 | |
| 3381128 | 29 LAMP AS-DOME (12/24-VOLT, LED) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 3749690 | 30 SWITCH AS-LIMIT (BRAKE LIGHT) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 3E3371 | WEDGE-RECEPTACLE LOCK (3-PIN) | 1 | |
| 4198146 | 31 GROMMET | 1 | |
| 4559568 | 32 CAP AS | 1 | |
| 4244322 | COVER-CONNECTOR | 1 | |
| 4613586 | 33 FILM-IDENTIFICATION (WASHER, WIPER SYSTEM) | 1 | |
| 4715437 | 34 BRACKET AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 2 | |
| 4900579 | 35 ADAPTER AS | 1 | |
| 4900588 | 36 NUT | 1 | |
| 4906751 | 37 HARNESS AS-CAB (LIGHTS) | 1 | |
| 5064260 | 38 APPLICATION GP-MONITOR (NETWORK MANAGER) | 1 | |
| 1305300 | 39 CLIP | 1 | |
| 1315171 | 40 CLIP | 4 | |
| 1325789 | 41 CLIP (LADDER) | 1 | |
| 1514957 | 42 BOLT-SOCKET HEAD (M3X0.5X25-MM) | 2 | |
| 1804028 | 43 BRACKET | 1 | |
| 1989706 | 44 SCREW-TRUSS HEAD (M5X0.8X16-MM) | 4 | |
| 2061346 | 45 STRAP-CABLE | 3 | |
| 2469371 | 46 COVER-RELAY | 5 | |
| 3445673 | 47 NUT (M6X1-THD) | 1 | |
| 3C6969 | 48 NUT (M3X0.5-THD) | 2 | |
| 4715420 | 49 PLATE | 1 | |
| 4906754 | 50 HARNESS AS-CAB (MAIN) | 1 | |
| 4906756 | 51 HARNESS AS-POWER (CHASSIS) | 1 | |
| 4906762 | 52 HARNESS AS-CAB (ROOF) | 1 | |
| 4P7581 | 53 CLIP (LADDER) | 1 | |
| 5219757 | 54 FILM-IDENTIFICATION (FUSE/RELAY PANEL) | 1 | |
| 5225058 | 55 PLATE | 1 | |
| 5284106 | 56 SWITCH AS-ROCKER (24-VOLT)(DIFFERENTIAL LOCK) | 1 | |
| 5C7261 | 57 NUT (M8X1.25-THD) | 2 | |
| 5C9553 | 58 BOLT (M6X1X16-MM) | 2 | |
| 5P4115 | 59 WASHER-HARD (7.2X19X2-MM THK) | 1 | |
| 5P6629 | 60 GROMMET | 2 | |
| 6V8214 | 61 BOLT (M6X1X20-MM) | 4 | |
| 7C4354 | 62 CLIP | 1 | |
| 7G7053 | 63 GROMMET | 2 | |
| 7I4698 | 64 RING | 1 | |
| 7X0608 | 65 WASHER-HARD (10.2X16X2-MM THK) | 2 | |
| 8C5608 | 66 SPACER (6.5X9.5X25.4-MM THK) | 4 | |
| 8C8451 | 67 BOLT (M6X1X40-MM) | 4 | |
| 8T4121 | 68 WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8T4137 | 69 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4191 | 70 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4970 | 71 BOLT (M6X1X14-MM) | 8 | |
| 2643617 | 72 LOCKWASHER | 2 | |
| 9G2673 | 73 GROMMET | 1 | |
| 9X1046 | 74 SCREW (M4X0.7X18-MM) | 6 | |
| 9X6155 | 75 BOLT-SOCKET HEAD (M6X1X16.7-MM) | 1 | |
| 9X6165 | 76 WASHER (6.5X22X2.5-MM THK) | 4 | |
| 9X8256 | 77 WASHER (6.6X12X2-MM THK) | 14 |
