469-8367 AXLE GP-FRONTS/N Y9A1-UP

Group No: 469-8367
Part NumberPart NameQty
2G56671 RETAINER2
2G86152 WASHER-THRUST (2.015X3.625X0.11-IN THK)4
2G86263 WASHER-THRUST (2.02X3.63X0.16-IN THK)2
2G86334 PIN2
2G87415 RING-METAL SEAL4
2G87686 WASHER (10.5X53.8X3-MM THK)4
2G87777 SEAL4
3B84858 ELBOW2
3B84899 FITTING-GREASE (1/8-27 PTF)12
5K528810 SEAL GP-DUO-CONE2
5K5129RING-SEALING2
5T090611 COVER2
7D864312 RETAINER2
8W229013 CYLINDER & MTG GP-STEERING1
8W465214 HOUSING-SPINDLE1
8W465315 HOUSING-SPINDLE1
8W529316 PIN4
8X343417 ARM AS-LEANING (LH)1
8W647617A PIN1
146184217B BUSHING1
146184317C BUSHING1
8X343518 ARM AS-LEANING (RH)1
8W649718A PIN1
146184218B BUSHING1
146184318C BUSHING1
9D979719 LOCK2
103912520 BAR AS1
2G862420A BUSHING2
131374021 LINK GP-STEERING1
134108122 AXLE AS-FRONT1
2G863122A BUSHING4
131442822B BUSHING2
248622523 SPINDLE2
433710524 SEAL-PIN8
508680925 CYLINDER & MTG GP-WHEEL LEAN1
030006026 CUP-BEARING (TAPERED ROLLER)2
030006127 CONE-BEARING (TAPERED ROLLER)2
0S159228 BOLT (5/8-11X1.25-IN)2
6C321029 BOLT (7/8-9X3-IN)2
2G874230 WASHER-HARD (20X65X5-MM THK)2
2H374031 BOLT (3/4-16X1.25-IN)4
2J350532 NUT-FULL (7/8-9-THD)2
2J816333 SEAL-O-RING2
3B461834 PIN-COTTER2
4D370435 WASHER-HARD (17X30X5-MM THK)2
5D035336 BOLT-LOCKING (3/8-16X1-IN)4
5P107537 WASHER-HARD (10.2X22.5X3-MM THK)4
5P884338 SEAL-LIP TYPE2
5P889039 SEAL-LIP TYPE2
5S737940 BOLT (3/8-16X0.875-IN)4
6V569641 BOLT (M12X1.75X80-MM)6
7D863642 CONE-BEARING2
7D863743 CUP-BEARING2
7X773144 PLUG-PIPE (3/4-14-THD)2
8D281145 WASHER (1.25X1.94X0.032-IN THK)2
9M209246 SEAL-O-RING4
2G386547 SHIM (0.127-MM THK)6
