System And Components
418-1985 PUMP GP-PISTONS/N Y9C1-UP
Group No: 418-1985
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3891201 | 1 ROTATING GP-PUMP | 1 | |
| 3516085 | 2 PISTON-CONTROL | 1 | |
| 2275904 | 3 SEAL-O-RING | 1 | |
| 3995839 | 4 SWASHPLATE | 1 | |
| 4168106 | 5 SHAFT-DRIVE | 1 | |
| 3746722 | 6 PLUG-CONTROL | 1 | |
| 8T7525 | 7 SEAL-O-RING | 1 | |
| 1051638 | 8 SPACER (30X38X3-MM THK) | 1 | |
| 1053031 | 9 CONE-BEARING | 1 | |
| 3B2263 | 10 CUP-BEARING | 1 | |
| 3516131 | 11 BEARING-CRADLE | 2 | |
| 2432737 | 12 SEAL-O-RING | 1 | |
| 1053032 | 13 CONE-BEARING | 1 | |
| 1053033 | 14 CUP-BEARING | 1 | |
| 3995838 | 15 PLATE-CONTROL | 1 | |
| 6V8201 | 16 BOLT-SOCKET HEAD (M16X2X45-MM) | 4 | |
| 9S4183 | 17 PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | 18 SEAL-O-RING | 1 | |
| 9X8979 | 19 DOWEL | 1 | |
| 4926229 | 20 VALVE GP-PUMP CONTROL | 1 | |
| 2807870 | 21 GASKET | 1 | |
| 8T8442 | 22 BOLT-SOCKET HEAD (M6X1X30-MM) | 4 | |
| 3795187 | 23 SPRING | 1 | |
| 1946848 | 24 COUPLER | 1 | |
| 3516352 | KIT-SEAL (PISTON) | 1 |
