System And Components
424-8591 REGULATOR GP-OIL LEVELS/N PRH1-UP
Group No: 424-8591
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W4979 | 1 VALVE-CHECK | 1 | |
| 2136133 | 2 REGULATOR AS | 1 | |
| 5458456 | COVER (REGULATOR) | 1 | |
| 5458457 | COVER (REGULATOR) | 1 | |
| 3422301 | 3 HOSE AS | 1 | |
| 3954047 | 4 HOSE AS-AIR | 1 | |
| 2807394 | 5 BRACKET AS | 1 | |
| 2A4639 | 6 BOLT (3/8-16X1.625-IN) | 2 | |
| 1697326 | 7 VALVE-BALL (SHUTOFF, OIL) | 1 | |
| 3B1915 | 8 BOLT (3/8-16X1.375-IN) | 3 | |
| 3B7741 | 9 NIPPLE-PIPE (CLOSE) | 2 | |
| 5M2894 | 10 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 3696847 | 11 CONNECTOR AS | 1 | |
| 8C6871 | CONNECTOR | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 2287090 | 12 SEAL-O-RING | 1 | |
| 3526493 | 13 ELBOW AS | 1 | |
| 2T2396 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3309763 | 14 CONNECTOR AS | 1 | |
| 8C6872 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 9X6458 | 15 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 9M5501 | 16 ELBOW-STREET | 1 | |
| 9S8752 | 18 NUT-FULL (3/8-16-THD) | 3 | |
| 3E7449 | 19 ELBOW | 1 | |
| 6B1628 | 20 BUSHING-REDUCER | 1 |
