461-8678 AXLE GP-FRONTS/N E941-UP

Group No: 461-8678

Part Number	Part Name	Qty
2G8615	1 WASHER-THRUST (2.015X3.625X0.11-IN THK)	4
2G8741	2 RING-METAL SEAL	4
3B8486	3 FITTING-GREASE (1/8-27 PTF)	2
3B8488	4 FITTING-GREASE (1/8-27 PTF)	2
3B8489	5 FITTING-GREASE (1/8-27 PTF)	10
5T0906	6 COVER	2
2486225	7 SPINDLE	2
2579799	8 PIN	4
2608602	9 WASHER (11X53.8X3-MM THK)	4
2608713	10 CYLINDER & MTG GP-WHEEL LEAN	1
2746816	11 LINK GP-STEERING	1
2794357	12 BAR AS	1
2G8624	12A BUSHING	2
3659252	13 HOUSING-SPINDLE (LH)	1
3659253	14 HOUSING-SPINDLE (RH)	1
3814308	15 ARM AS (LH)	1
1461842	15A BUSHING	1
1461843	15B BUSHING	1
2794355	PIN	1
3814309	16 ARM AS (RH)	1
1461842	16A BUSHING	1
1461843	16B BUSHING	1
2794356	PIN	1
4337105	17 SEAL-PIN	4
4618679	18 AXLE AS-FRONT	1
4698359	19 CYLINDER & MTG GP-STEERING	1
0300060	20 CUP-BEARING (TAPERED ROLLER)	2
0300061	21 CONE-BEARING (TAPERED ROLLER)	2
1488395	22 PLUG AS	2
3K0360	SEAL-O-RING	1
9S8005	PLUG (3/4-16-THD)	1
1551142	23 WASHER (17X71X5-MM THK)	3
1984768	24 WASHER-HARD (17.5X32X8-MM THK)	3
2607486	25 PIN	2
2667315	26 WASHER-HARD (22X65X6-MM THK)	2
2972537	27 LOCK	2
2G8626	28 WASHER-THRUST (2.02X3.63X0.16-IN THK)	2
2G8777	29 SEAL	4
2J8163	30 SEAL-O-RING	2
3B4618	31 PIN-COTTER	2
5K5288	32 SEAL GP-DUO-CONE	2
5K5129	RING-SEALING	2
5M6214	33 PLUG (1/8-27 PTF)	4
5P8890	34 SEAL-LIP TYPE	2
6V5696	35 BOLT (M12X1.75X80-MM)	6
6V5844	36 BOLT (M16X2X35-MM)	3
6V8133	37 BOLT (M24X3X80-MM)	2
7D8636	38 CONE-BEARING	2
7D8637	39 CUP-BEARING	2
7D8643	40 RETAINER	2
7X0851	41 NUT (M24X3-THD)	2
7X2561	42 BOLT (M20X2.5X35-MM)	4
7X7729	43 WASHER (11X25X3-MM THK)	4
8T4137	44 BOLT (M10X1.5X20-MM)	4
9M2092	45 SEAL-O-RING	4
9X2125	46 BOLT-LOCKING (M10X1.5X25-MM)	4
2G3865	47 SHIM (0.127-MM THK)	6
