System And Components
559-2892 LINES GP-TRANSMISSION OILS/N E941-UP
Group No: 559-2892
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8C3446 | 1 VALVE-SAMPLING (TRANSMISSION OIL) | 1 | |
| 8C3447 | 2 CAP-DUST | 1 | |
| 8T7934 | 3 WASHER-HARD (11X21X5-MM THK) | 2 | |
| 8X5121 | 4 TUBE | 1 | |
| 8X7317 | 5 HOSE | 1 | |
| 8X8916 | 6 PLATE | 1 | |
| 9C5344 | 7 SPACER (10.5X20X18-MM THK) | 1 | |
| 9C9467 | 8 CLIP | 1 | |
| 9S8005 | 9 PLUG (3/4-16-THD) | 2 | |
| 1139048 | 10 BAFFLE | 1 | |
| 1180424 | 11 ADAPTER | 1 | |
| 1260747 | 12 VALVE GP-BYPASS (TRANSMISSION OIL) | 1 | |
| 1488406 | 13 PLUG AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 1536237 | 14 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645567 | 15 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 7M8485 | 16 SEAL-O-RING | 1 | |
| 8J0426 | 17 PLUG | 1 | |
| 2416215 | 18 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8076 | ELBOW | 1 | |
| 3328833 | 19 FILTER GP-OIL (MEDIUM PRESSURE)(TRANSMISSION) | 1 | |
| 8T4178 | 20 BOLT (M10X1.5X90-MM) | 2 | |
| 2416217 | 21 ELBOW | 1 | |
| 1488392 | 22 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 6V9853 | ELBOW | 1 | |
| 4358315 | 23 HOSE AS | 1 | |
| 4358316 | 24 TUBE AS | 1 | |
| 4358321 | 25 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4420289 | 26 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 8T4195 | 27 BOLT (M10X1.5X30-MM) | 4 | |
| 8T4196 | 28 BOLT (M10X1.5X35-MM) | 8 | |
| 4739331 | 29 HOSE AS | 1 | |
| 5136521 | 30 BRACKET AS | 1 | |
| 5D9629 | ROD | 1 | |
| 9R2613 | BOSS-WELD (M10X1.5X25-MM) | 1 | |
| 9R2672 | BOSS-THREADED (M10X1.5X20-MM) | 1 | |
| 8T4183 | 31 BOLT (M12X1.75X40-MM) | 1 | |
| 5197022 | 32 HOSE AS | 1 | |
| 5201957 | 33 HOSE AS | 1 | |
| 0324036 | 34 FITTING | 2 | |
| 0673045 | 35 CLIP (LOOP) | 1 | |
| 1305300 | 36 CLIP | 1 | |
| 1488352 | 37 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488335 | 38 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488339 | 39 CONNECTOR AS | 3 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488357 | 40 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488360 | 41 ELBOW AS | 2 | |
| 6V9182 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T4983 | 42 CLAMP-HOSE | 2 | |
| 1504049 | 43 ELBOW AS | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T4149 | ELBOW | 1 | |
| 1833407 | 44 PLUG AS | 2 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1P4578 | 45 FLANGE-HALF | 2 | |
| 8T6466 | 46 BOLT (M10X1.5X60-MM) | 8 | |
| 3D2824 | 47 SEAL-O-RING | 1 | |
| 3J1907 | 48 SEAL-O-RING | 1 | |
| 3J7354 | 49 SEAL-O-RING | 1 | |
| 3K0360 | 50 SEAL-O-RING | 2 | |
| 4D7388 | 51 CLIP | 1 | |
| 4F7389 | 52 SEAL-O-RING | 2 | |
| 4J0520 | 53 SEAL-O-RING | 4 | |
| 4J0522 | 54 SEAL-O-RING | 1 | |
| 4S1962 | 55 CLIP (LOOP) | 1 | |
| 5201958 | 56 HOSE AS | 1 | |
| 5416625 | 57 CLIP (LOOP) | 2 | |
| 5560072 | 58 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 5594884 | 59 HOSE AS | 1 | |
| 5602360 | 60 HOSE AS | 1 | |
| 5D1026 | 61 CLAMP-BAND | 2 | |
| 5K9090 | 62 SEAL-O-RING | 2 | |
| 8T4223 | 63 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6V0852 | 64 CAP-DUST | 1 | |
| 6V9746 | 65 SEAL-O-RING | 1 | |
| 7X0342 | 66 BOLT (5/8-11X0.75-IN) | 1 | |
| 7X2552 | 67 BOLT (M16X2X30-MM) | 2 | |
| 8C3206 | 68 FLANGE-HALF | 6 | |
| 8C8417 | 69 CONNECTOR | 1 | |
| 8T4121 | 70 WASHER-HARD (11X21X2.5-MM THK) | 29 | |
| 8T4136 | 71 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4137 | 72 BOLT (M10X1.5X20-MM) | 3 | |
| 9X8257 | 73 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 5P0765 | 74 HOSE (54-CM) |
