System And Components
521-8919 LINES GP-SERVICE BRAKE -ALL WHEEL DRIVES/N E931-UP
Group No: 521-8919
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1013129 | 1 STUD (M10X1.5-THD) | 2 | |
| 1027886 | 2 SPACER (11X20X80-MM THK) | 1 | |
| 1163715 | 3 STUD-TAPERLOCK (M10X1.5X85-MM) | 1 | |
| 1243019 | 4 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1488328 | 5 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8633 | CONNECTOR | 1 | |
| 1488340 | 6 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488354 | 7 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488364 | 8 ELBOW AS | 3 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488380 | 9 ELBOW AS | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8988 | ELBOW | 1 | |
| 1488428 | 10 TEE AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8782 | TEE | 1 | |
| 1488444 | 11 TEE AS-SWIVEL | 2 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 1F7854 | 12 SPACER (11.01X19.05X49.21-MM THK) | 2 | |
| 2018357 | 13 BRACKET | 1 | |
| 2276715 | 14 STUD (M10X1.5X30-MM) | 2 | |
| 2310336 | 15 STUD-TAPERLOCK (M10X1.5X70-MM) | 4 | |
| 2751442 | 16 CLIP (TAB) | 3 | |
| 2751443 | 17 CLIP (SLOT) | 3 | |
| 2751444 | 18 GROMMET | 3 | |
| 2884402 | 19 STUD-TAPERLOCK (M10X1.5X60-MM) | 2 | |
| 2887158 | 20 STUD (M10X1.5X125-MM) | 2 | |
| 3445675 | 21 NUT (M10X1.5-THD) | 14 | |
| 3537952 | 22 GROMMET | 4 | |
| 3S8665 | 23 CLIP (LOOP) | 1 | |
| 4310709 | 24 STUD-TAPERLOCK (M10X1.5X150-MM) | 1 | |
| 4556168 | 25 HOSE AS | 2 | |
| 4631285 | 26 BLOCK | 1 | |
| 4631286 | 27 BLOCK | 1 | |
| 4631289 | 28 BLOCK | 1 | |
| 4631290 | 29 BLOCK | 2 | |
| 4739300 | 30 BLOCK | 1 | |
| 4739301 | 31 BLOCK | 1 | |
| 4739302 | 32 BLOCK | 1 | |
| 4739303 | 33 BLOCK | 1 | |
| 4739306 | 34 PLATE | 1 | |
| 4739307 | 35 BRACKET AS | 1 | |
| 2723757 | BOSS (M10X1.5X100-MM) | 2 | |
| 4770555 | 36 PLATE | 2 | |
| 4786604 | 37 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 4795711 | 38 HOSE AS | 1 | |
| 4906702 | 39 BLOCK | 1 | |
| 4906703 | 40 BLOCK | 1 | |
| 4906723 | 41 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 2944550 | BOSS-WELD (M10X1.5X60-MM) | 1 | |
| 4906743 | 42 HOSE AS | 1 | |
| 4906744 | 43 HOSE AS | 1 | |
| 4906745 | 44 HOSE AS | 1 | |
| 4906746 | 45 HOSE AS | 1 | |
| 4906749 | 46 HOSE AS | 1 | |
| 4J0520 | 47 SEAL-O-RING | 1 | |
| 5241486 | 48 BLOCK | 1 | |
| 5241487 | 49 BLOCK | 1 | |
| 5241488 | 50 BLOCK | 2 | |
| 5241489 | 51 HOSE AS | 1 | |
| 5253640 | 52 HOSE AS | 1 | |
| 5328183 | 53 TUBE AS | 1 | |
| 5416632 | 54 CLIP (LOOP) | 5 | |
| 5626052 | 55 BRACKET AS | 1 | |
| 9R2672 | BOSS-THREADED (M10X1.5X20-MM) | 1 | |
| 9R3761 | BOSS (M10X1.5X51-MM) | 2 | |
| 2723757 | BOSS (M10X1.5X100-MM) | 2 | |
| 5626053 | 56 PLATE | 1 | |
| 5626054 | 57 PLATE AS | 1 | |
| 1273387 | BOSS (M10X1.5X80-MM) | 1 | |
| 5626055 | 58 PLATE AS | 1 | |
| 9R9866 | BOSS-THREADED (M10X1.5-THD) | 1 | |
| 5646801 | 59 BLOCK | 1 | |
| 5646802 | 60 BLOCK | 1 | |
| 5646803 | 61 BLOCK | 1 | |
| 5657341 | 62 HOSE AS | 1 | |
| 5658674 | 63 HOSE AS | 1 | |
| 5664016 | 64 HOSE AS | 1 | |
| 6D4246 | 65 CLIP (LOOP) | 7 | |
| 6V9169 | 66 NUT (13/16-16-THD) | 2 | |
| 7S3916 | 67 CLIP (TAB) | 2 | |
| 7S3919 | 68 CLIP (SLOT) | 2 | |
| 7V6571 | 69 GROMMET | 2 | |
| 7X7729 | 70 WASHER (11X25X3-MM THK) | 1 | |
| 8C3206 | 71 FLANGE-HALF | 2 | |
| 8M2773 | 72 CLIP (LOOP) | 5 | |
| 8T1897 | 73 CLIP (SLOT) | 4 | |
| 8T1898 | 74 CLIP (TAB) | 4 | |
| 8T4121 | 75 WASHER-HARD (11X21X2.5-MM THK) | 47 | |
| 8T4123 | 76 WASHER (22X35X3.5-MM THK) | 2 | |
| 8T4136 | 77 BOLT (M10X1.5X25-MM) | 15 | |
| 8T4137 | 78 BOLT (M10X1.5X20-MM) | 6 | |
| 8T4195 | 79 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 80 BOLT (M10X1.5X35-MM) | 7 |
