System And Components
444-5326 SCARIFIER GP -VEE TYPES/N E951-UP
Group No: 444-5326
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G4332 | 1 BLOCK AS-SCARIFIER | 1 | |
| 7D8825 | SPACER | 11 | |
| 7D8826 | SPACER | 11 | |
| 3B8489 | 2 FITTING-GREASE (1/8-27 PTF) | 4 | |
| 4D6086 | 3 KEY | 2 | |
| 5B0577 | 4 COLLAR | 2 | |
| 5D8159 | 5 PIN AS | 2 | |
| 5K1458 | 6 GROMMET | 11 | |
| 5K1459 | 7 LOCK PIN | 11 | |
| 6F6992 | 8 CAP-BALL SOCKET | 4 | |
| 6Y5230 | 9 TOOTH-SCARIFIER | 11 | |
| 7D2196 | 10 SLEEVE AS-LINK | 2 | |
| 7D2136 | SOCKET-BALL | 1 | |
| 7F1327 | 11 SHIM (0.03-IN THK) | 32 | |
| 8D1268 | 12 ARM AS-LIFT | 2 | |
| 7D8245 | STUD-BALL | 1 | |
| 8W0663 | 13 BRACKET AS | 2 | |
| 3B8489 | FITTING-GREASE (1/8-27 PTF) | 1 | |
| 1078374 | BEARING | 2 | |
| 9D5516 | 14 LINK AS-LIFT | 2 | |
| 7D2135 | SOCKET-BALL | 1 | |
| 1078375 | 15 SHAFT AS | 1 | |
| 1187880 | 16 DRAWBAR AS | 1 | |
| 1187881 | 17 DRAWBAR AS | 1 | |
| 2G7728 | COLLAR | 2 | |
| 8W5597 | STUD-BALL | 1 | |
| 1957218 | 18 SHANK | 11 | |
| 1989811 | 19 SPACER (83X145X3-MM THK) | 16 | |
| 1989812 | 20 SPACER (83X145X2-MM THK) | 3 | |
| 3306877 | 21 SHAFT | 1 | |
| 2993436 | 22 BOLT (7/8-9X3.5-IN) | 2 | |
| 3293710 | 23 NUT (1-1/8-7-THD) | 4 | |
| 5D8161 | 24 PIN | 2 | |
| 6K0545 | 25 LOCKNUT (7/8-9-THD) | 6 | |
| 6K3632 | 26 LOCKNUT (1-8-THD) | 4 | |
| 6V8188 | 27 NUT (1/2-13-THD) | 2 | |
| 7X0328 | 28 BOLT (1/2-13X3.5-IN) | 2 | |
| 6C3220 | 29 BOLT (7/8-9X5-IN) | 4 | |
| 7X0423 | 30 BOLT (1-1/8-7X4.5-IN) | 4 | |
| 7X0443 | 31 BOLT (1-8X5.5-IN) | 4 | |
| 8C6913 | 32 WASHER-HARD (24X41.5X4-MM THK) | 4 | |
| 8T4223 | 33 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4994 | 34 WASHER-HARD (20X36.5X3.5-MM THK) | 8 | |
| 8T5361 | 35 WASHER-HARD (28X49X5-MM THK) | 8 | |
| 8T8924 | 36 BOLT (3/4-10X2.5-IN) | 8 | |
| 9X8258 | 37 WASHER (33X56X6-MM THK) | 4 | |
| 6B3260 | TOOL | 1 |
