System And Components
470-5238 WIRING GP-COMMUNICATIONS/N RJZ1-UP
Group No: 470-5238
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 12 | |
| 8T4983 | 2 CLAMP-HOSE | 1 | |
| 8T8737 | 3 PLUG-SEAL | 8 | |
| 1114838 | 4 CLIP | 1 | |
| 2504674 | 5 BOOT-RUBBER | 1 | |
| 2934950 | 6 FILM-IDENTIFICATION (DISCONNECT) | 1 | |
| 3523968 | 7 CLIP (LADDER) | 1 | |
| 3534515 | 8 SWITCH GP-TOGGLE (COMMUNICATION ON/OFF) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 3858201 | 9 CAP AS-CONNECTOR | 2 | |
| 4402105 | 10 CONTROL GP-ELECTRONIC (PL641E CELLULAR) | 1 | |
| 1552265 | 11 KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 2S9727 | 12 GROMMET | 1 | |
| 3538773 | 13 CABLE AS-COAXIAL | 1 | |
| 4H2558 | 14 GROMMET | 1 | |
| 4P7581 | 15 CLIP (LADDER) | 1 | |
| 5M3062 | 16 BOLT (3/8-16X0.75-IN) | 1 | |
| 6D3479 | 17 CLIP (LOOP) | 1 | |
| 6K8178 | 18 CLIP (LOOP) | 3 | |
| 6V7357 | 19 BOLT (M6X1X25-MM) | 4 | |
| 8T4121 | 20 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4133 | 21 NUT (M10X1.5-THD) | 1 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4191 | 23 BOLT (M10X1.5X16-MM) | 3 | |
| 8T4896 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9X8256 | 25 WASHER (6.6X12X2-MM THK) | 4 |
