System And Components
528-9491 LINES GP-WATERS/N NGH1-UP
Group No: 528-9491
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4V6698 | 1 SPACER (10X16X16-MM THK) | 2 | |
| 3920802 | 2 CONNECTOR AS | 1 | |
| 6V5063 | SEAL-O-RING | 1 | |
| 6V8633 | CONNECTOR | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 4288808 | 3 CLAMP-HOSE | 4 | |
| 4858985 | 4 CLIP | 5 | |
| 4858986 | 5 CLIP | 5 | |
| 5261836 | 6 CONNECTOR AS | 1 | |
| 6D7128 | SEAL-O-RING | 1 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 6V8715 | CONNECTOR | 1 | |
| 5289492 | 7 TUBE AS | 1 | |
| 5289493 | 8 TUBE AS | 1 | |
| 5289494 | 9 HOSE | 1 | |
| 5289495 | 10 HOSE | 1 | |
| 1452264 | 11 STUD (M8X1.25X35-MM) | 2 | |
| 3445674 | 12 NUT (M8X1.25-THD) | 2 | |
| 3445675 | 13 NUT (M10X1.5-THD) | 1 | |
| 5K9660 | 14 CLIP (LOOP) | 2 | |
| 8T4121 | 15 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4189 | 16 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 9X2027 | 18 WASHER (11X18X2-MM THK) | 1 |
