System And Components
529-0174 WIRING GP-ELECTRONIC CONTROLS/N NGH1-UP
Group No: 529-0174
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 14 | |
| 7K1181 | 2 STRAP-CABLE | 7 | |
| 1640150 | 3 SPACER (9X20X20-MM THK) | 1 | |
| 2905664 | 4 STRAP-CABLE | 6 | |
| 5253964 | 5 HARNESS AS-CONTROL (JUMPER) | 1 | |
| 5464250 | 6 WIRING GP-ENGINE | 1 | |
| 5396196 | 7 SPACER (9X16X70-MM THK) | 1 | |
| 1013129 | 8 STUD (M10X1.5-THD) | 1 | |
| 1325789 | 9 CLIP (LADDER) | 2 | |
| 1783336 | 10 NUT-HEX FLANGE (M8X1.25-THD) | 5 | |
| 1757141 | 11 NUT-HEX FLANGE (M10X1.5-THD) | 1 | |
| 3094314 | 12 CLIP (LADDER) | 1 | |
| 3E4353 | 13 WASHER-HARD (11X25X3-MM THK) | 1 | |
| 4P7581 | 14 CLIP (LADDER) | 1 | |
| 5L2087 | 15 SPACER (9.25X13.72X50.8-MM THK) | 1 | |
| 5P8347 | 16 BOLT (M8X1.25X70-MM) | 1 | |
| 6V5215 | 17 BOLT (M8X1.25X16-MM) | 1 | |
| 6V5839 | 18 WASHER (11X21X2.5-MM THK) | 1 | |
| 8T4196 | 19 BOLT (M10X1.5X35-MM) | 1 | |
| 8T0292 | 20 BOLT (M8X1.25X90-MM) | 1 | |
| 8T4138 | 21 BOLT (M6X1X20-MM) | 1 | |
| 9M1974 | 22 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X8256 | 23 WASHER (6.6X12X2-MM THK) | 1 | |
| 1064159 | 24 SPACER (11.13X19.05X13.5-MM THK) | 1 | |
| 2574907 | 25 COVER AS-ACCESS | 1 |
