Assembly
100%

531-2441 WIRING GP-ELECTRONIC CONTROLS/N NGH1-UP

Group No: 531-2441
Part NumberPart NameQty
3S20931 STRAP-CABLE12
7K11812 STRAP-CABLE8
16401503 SPACER (9X20X20-MM THK)1
29056644 STRAP-CABLE6
31612475 STRAP-CABLE2
52539646 HARNESS AS-CONTROL (JUMPER)1
54642507 WIRING GP-ENGINE1
53961968 SPACER (9X16X70-MM THK)1
10131299 STUD (M10X1.5-THD)1
132578910 CLIP (LADDER)1
178333611 NUT-HEX FLANGE (M8X1.25-THD)5
175714112 NUT-HEX FLANGE (M10X1.5-THD)1
309431413 CLIP (LADDER)1
3E435314 WASHER-HARD (11X25X3-MM THK)1
4P758115 CLIP (LADDER)1
5L208716 SPACER (9.25X13.72X50.8-MM THK)1
5P834717 BOLT (M8X1.25X70-MM)1
6V521518 BOLT (M8X1.25X16-MM)1
6V583919 WASHER (11X21X2.5-MM THK)1
8T419620 BOLT (M10X1.5X35-MM)1
8T029221 BOLT (M8X1.25X90-MM)1
9M197422 WASHER-HARD (8.8X16X2-MM THK)4
106415923 SPACER (11.13X19.05X13.5-MM THK)1
257490724 COVER AS-ACCESS1
