System And Components
389-3790 CONTROL GP-TRANSMISSION HYDS/N PFW602-UP
Group No: 389-3790
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4F4097 | 1 SEAL-O-RING | 1 | |
| 6D7889 | 2 SEAL-O-RING | 6 | |
| 8C6354 | 3 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 1803178 | 4 VALVE GP-RELIEF (TORQUE CONVERTER INLET) | 1 | |
| 1974652 | 5 VALVE-RELIEF (CLUTCH BACK PRESSURE) | 1 | |
| 2142485 | 6 SENSOR GP-SPEED (TORQUE CONVERTER OUTPUT)(TORQUE CONVERTER OUTPUT) | 1 | |
| 2345013 | 7 SENSOR GP-TEMPERATURE (TRANSMISSION OIL) | 1 | |
| 2345013 | 7A SENSOR GP-TEMPERATURE (TORQUE CONVERTER OIL) | 1 | |
| 2366222 | 8 SENSOR GP-SPEED (TRANSMISSION OUTPUT) | 2 | |
| 2366222 | 8A SENSOR GP-SPEED (ENGINE) | 1 | |
| 2447772 | 9 VALVE GP-MODULATING | 6 | |
| 2915742 | 10 KIT-SEAL (LUBRICATION) | 1 | |
| 3045687 | 11 CONTROL GP-UNPROGRAMMED (TRANSMISSION) | 1 | |
| 4647451 | 12 HARNESS AS-CONTROL (TRANSMISSION) | 1 | |
| 3452309 | 13 BRACKET AS | 1 | |
| 8R1496 | SPACER (10X20X29-MM THK) | 4 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 3710891 | 14 PLATE-SEPARATOR (TRANSMISSION) | 1 | |
| 3710892 | 15 GASKET | 1 | |
| 3830811 | 16 VALVE GP-RELIEF (OIL CONTROL) | 1 | |
| 3452300 | 17 HARNESS AS-TRANSMISSION | 1 | |
| 0965866 | 19 BOLT (M8X1.25X75-MM) | 4 | |
| 1305300 | 20 CLIP | 1 | |
| 1325789 | 21 CLIP (LADDER) | 5 | |
| 3207691 | 22 CLIP (LOOP) | 1 | |
| 1833409 | 23 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 0335853 | SEAL-O-RING | 1 | |
| 2859066 | 25 BOLT (M8X1.25X65-MM) | 12 | |
| 3523968 | 26 CLIP (LADDER) | 1 | |
| 3535126 | 27 PLUG AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 3S2093 | 28 STRAP-CABLE | 13 | |
| 4P7428 | 29 CLIP (LADDER) | 2 | |
| 4P7429 | 30 CLIP (LADDER) | 1 | |
| 4P7581 | 31 CLIP (LADDER) | 3 | |
| 5S1522 | 32 RING-SNAP | 2 | |
| 6D5801 | 33 LOCKNUT (8-32-THD) | 8 | |
| 6I1418 | 34 SPACER (8.2X12.7X28.7-MM THK) | 4 | |
| 6V0852 | 35 CAP-DUST | 7 | |
| 6V2480 | 36 SCREW (4-40X0.5-IN) | 4 | |
| 1645567 | 37 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V5839 | 38 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V8352 | 39 SEAL-O-RING | 2 | |
| 7K1181 | 40 STRAP-CABLE | 4 | |
| 7U4892 | 41 SCREW (8-32X0.75-IN) | 8 | |
| 8T4136 | 42 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4189 | 43 BOLT (M8X1.25X20-MM) | 3 | |
| 8T4224 | 45 WASHER-HARD (8.8X16X2-MM THK) | 30 | |
| 2822628 | 46 BOLT (M8X1.25X30-MM) | 12 | |
| 6V5216 | 47 BOLT (M8X1.25X18-MM) | 5 | |
| 8T6912 | 48 BOLT (M8X1.25X50-MM) | 8 | |
| 8T9655 | 50 MOUNT-ISOLATION | 8 | |
| 9M8406 | 51 CLIP (LOOP) | 1 | |
| 9N0869 | 52 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 9N7446 | 53 LOCKNUT (4-40-THD) | 4 | |
| 1984776 | 54 WASHER-HARD (8.8X20X8-MM THK) | 11 |
