System And Components
339-3916 PAN GP-TRANSMISSION OILS/N GFY300-UP
Group No: 339-3916
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8S9129 | 1 FILTER-MAGNETIC (TRANSMISSION OIL PAN) | 1 | |
| 8S9130 | 2 SCREEN-SUCTION (TRANSMISSION OIL) | 1 | |
| 1833398 | 3 CONNECTOR AS | 2 | |
| 6V8636 | CONNECTOR | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 8L2779 | SEAL-O-RING | 1 | |
| 2664198 | 4 HOUSING-SCREEN | 1 | |
| 2680226 | 5 SEAL | 1 | |
| 2767342 | 6 TUBE AS | 1 | |
| 2911123 | 7 GUARD | 1 | |
| 3058956 | 8 PAN-OIL | 1 | |
| 3393905 | 9 COVER | 1 | |
| 6V3551 | 10 SEAL-O-RING | 1 | |
| 6V3822 | 11 BOLT (M10X1.5X35-MM) | 2 | |
| 6V5839 | 12 WASHER (11X21X2.5-MM THK) | 2 | |
| 8C5230 | 13 SEAL-O-RING | 1 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 24 | |
| 8T4189 | 15 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4908 | 17 BOLT (M8X1.25X25-MM) | 3 | |
| 8T6466 | 18 BOLT (M10X1.5X60-MM) | 24 | |
| 3095133 | 19 PLUG AS | 1 | |
| 9S4181 | PLUG (1-5/16-12-THD)(TRANSMISSION OIL DRAIN) | 1 | |
| 2385084 | SEAL-O-RING | 1 |
