System And Components
383-0811 VALVE GP-RELIEF -OIL CONTROLS/N PFW452-UP; GFY300-UP
Group No: 383-0811
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1M9351 | 1 SPRING | 1 | |
| 2S4663 | 2 SEAL-O-RING | 1 | |
| 2S5835 | 3 PISTON-LOAD | 1 | |
| 9M1974 | 4 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 3218641 | 5 PLUG AS | 3 | |
| 9S8001 | PLUG (5/16-24-THD) | 1 | |
| 2385078 | SEAL-O-RING | 1 | |
| 8E1143 | 6 SLUG | 1 | |
| 8M5253 | 7 SEAL-O-RING | 1 | |
| 9M2110 | 8 COVER-ADJUSTMENT | 1 | |
| 9U8668 | 9 SPOOL AS | 1 | |
| 3D8317 | RING-RETAINING | 1 | |
| 4B9880 | BALL | 1 | |
| 4M2381 | SPRING | 1 | |
| 8E9893 | SPOOL-RELIEF | 1 | |
| 9U8669 | RETAINER | 1 | |
| 1113200 | 10 BODY | 1 | |
| 2022005 | 11 COVER | 1 | |
| 2022006 | 12 SCREW-ADJUSTMENT | 1 | |
| 6V5218 | 13 BOLT (M8X1.25X35-MM) | 2 | |
| 1620177 | 14 PLUG AS | 2 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3940 | 15 BOLT (M8X1.25X25-MM) | 2 |
