System And Components
526-0671 INSTRUMENT GPS/N NGH1-UP
Group No: 526-0671
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P8500 | 1 KEY (CORPORATE) | 1 | |
| 1082515 | 2 COVER-TERMINAL | 2 | |
| 1893158 | 3 SUPPRESSOR-ARC | 1 | |
| 2039007 | 4 NUT (1-1/2-18-THD) | 1 | |
| 2313930 | 5 RELAY AS (24-VOLT)(FUEL PUMP) | 1 | |
| 2313930 | 5A RELAY AS (24-VOLT)(SHUTDOWN) | 1 | |
| 2418368 | 6 SWITCH GP-MAGNETIC (24-VOLT)(MAIN RELAY) | 1 | |
| 2552752 | 7 SWITCH GP-START (IGNITION) | 1 | |
| 2603733 | 8 CIRCUIT BREAKER AS (5-AMPERE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 2702679 | 9 LOCKWASHER | 1 | |
| 3407298 | 10 CAP AS-PROTECTION | 1 | |
| 3874299 | 11 BOX AS-INSTRUMENT | 1 | |
| 4878462 | 12 MODULE GP-KEYPAD | 1 | |
| 5259027 | 13 FILM-IDENTIFICATION | 1 | |
| 5260690 | 14 HARNESS AS-PANEL | 1 | |
| 5260691 | 15 PLATE | 1 | |
| 5260709 | 16 DISPLAY GP-MONITOR | 1 | |
| 3816884 | KIT-MOUNTING BRACKET | 2 | |
| 5260848 | SOFTWARE GP-MONITOR | 1 | |
| 5263979 | 17 BRACKET AS | 1 | |
| 1305300 | 18 CLIP | 2 | |
| 2110052 | 19 NUT (1-11/16-18-THD) | 1 | |
| 3100674 | 20 LOCKWASHER | 1 | |
| 3S2093 | 21 STRAP-CABLE | 4 | |
| 6T3643 | 22 CIRCUIT BREAKER AS (15-AMPERE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 6T3644 | 23 CIRCUIT BREAKER AS (20-AMPERE) | 3 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 6T3645 | 24 CIRCUIT BREAKER GP (60-AMPERE) | 1 | |
| 8T4138 | 25 BOLT (M6X1X20-MM) | 2 | |
| 8T4224 | 26 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4970 | 27 BOLT (M6X1X14-MM) | 6 | |
| 9X2044 | 28 SCREW-TRUSS HEAD (M6X1X16-MM) | 4 | |
| 9X6165 | 29 WASHER (6.5X22X2.5-MM THK) | 2 | |
| 9X8256 | 30 WASHER (6.6X12X2-MM THK) | 6 | |
| 9X8486 | 31 SCREW-MACHINE (8-32X0.75-IN) | 12 |
