442-3610 WIRING GP-POWER TRAINS/N HRT1-106

Group No: 442-3610

Part Number	Part Name	Qty
1252706	1 PLATE AS	1
1935576	2 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	1
2110052	3 NUT (1-11/16-18-THD)	1
2356162	4 PLATE	2
2909001	5 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
3197979	6 STRAP AS	2
3376678	7 PLATE	1
3979469	8 BRACKET AS	1
8T3490	NUT-WELD (M10X1.5-THD)	4
3981083	9 BRACKET	1
4423801	10 HARNESS AS-REAR (INTERCONNECT)	1
4423861	11 HARNESS AS-PLATFORM (FINAL DRIVE)	1
4647513	12 GRIP AS	1
4712099	13 HARNESS AS-SENSOR (POWER TRAIN)	1
4792171	14 BOLT AS	1
0673045	15 CLIP (LOOP)	1
0919035	16 SPACER (11X25X20-MM THK)	1
1497738	17 CLIP (LOOP)	2
0L1351	18 BOLT (3/8-16X0.875-IN)	1
1305300	19 CLIP	8
1305301	20 CLIP	3
1337810	21 STUD-TAPERLOCK (M10X1.5X45-MM)	3
1783620	22 STRAP-DUAL CLAMP	5
1F7958	23 NUT-FULL (1/2-13-THD)	1
1S0994	24 CLIP (LOOP)	9
2006345	25 SADDLE-MOUNTING (DUAL SWIVEL)	1
2042281	26 STRAP-CABLE	2
3107300	27 CLIP (LOOP)	1
3B4508	28 LOCKWASHER	1
4D9517	29 CLIP	8
4M0061	30 BOLT (5/16-18X0.75-IN)	1
5C8312	31 NUT (M4X0.7-THD)	4
5K3294	33 CLIP	5
5M3062	34 BOLT (3/8-16X0.75-IN)	4
5P1075	35 WASHER-HARD (10.2X22.5X3-MM THK)	2
6V1889	36 CLIP (LOOP)	2
6V8801	37 NUT (3/8-16-THD)	1
8C9660	38 WASHER (4.6X7.9X0.8-MM THK)	8
8T4186	39 BOLT (M10X1.5X40-MM)	1
8T4121	40 WASHER-HARD (11X21X2.5-MM THK)	21
8T4133	41 NUT (M10X1.5-THD)	4
8T4136	42 BOLT (M10X1.5X25-MM)	7
8T4191	43 BOLT (M10X1.5X16-MM)	5
8T4195	44 BOLT (M10X1.5X30-MM)	5
8T4223	45 WASHER-HARD (13.5X25.5X3-MM THK)	1
8T4224	46 WASHER-HARD (8.8X16X2-MM THK)	1
8T4896	47 WASHER-HARD (10.2X18.5X2.5-MM THK)	4
8T8917	48 BOLT (1/2-13X1.25-IN)	1
1622165	49 BOLT-SOCKET HEAD (M4X0.7X16-MM)	4
7X7729	50 WASHER (11X25X3-MM THK)	3
3445675	51 NUT (M10X1.5-THD)	3
