System And Components
518-5005 LINES GP-TURBOCHARGER WATERPART OF 502-3580 ENGINE AR-COMPLETE
Group No: 518-5005
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5020249 | 1 BRACKET | 1 | |
| 4P3563 | 2 CLAMP AS | 8 | |
| 1081434 | GROMMET | 1 | |
| 7E7264 | 3 CONNECTOR | 1 | |
| 7N3368 | 4 GASKET | 1 | |
| 8M5857 | 5 CLAMP | 2 | |
| 1381916 | 6 TEE-BULKHEAD | 1 | |
| 1442980 | 7 HOUSING | 1 | |
| 1529254 | 8 CONNECTOR | 1 | |
| 1759494 | 9 ADAPTER AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 5457503 | ADAPTER | 1 | |
| 2083786 | 10 CONNECTOR | 1 | |
| 2760792 | 11 CLAMP | 4 | |
| 2760794 | 12 PLATE | 2 | |
| 3028832 | 13 CONNECTOR | 2 | |
| 3048016 | 14 FITTING-SWIVEL | 1 | |
| 3535141 | 15 PLUG AS | 4 | |
| 9S8009 | PLUG-O-RING | 1 | |
| 2918145 | SEAL-O-RING | 1 | |
| 3696847 | 16 CONNECTOR AS | 2 | |
| 8C6871 | CONNECTOR | 1 | |
| 1808424 | SEAL-O-RING | 1 | |
| 3893733 | 17 PLUG AS | 1 | |
| 6V3251 | SEAL-O-RING | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 4152887 | 18 SEAL-O-RING | 2 | |
| 4391863 | 19 ADAPTER AS | 1 | |
| 6V9839 | TEE-SWIVEL | 1 | |
| 2949072 | SEAL-O-RING | 2 | |
| 4599402 | 20 HOSE AS | 1 | |
| 5056944 | 21 HOSE & TUBE AS | 1 | |
| 5139304 | 22 TUBE AS | 1 | |
| 5150044 | 23 HOSE & TUBE AS | 1 | |
| 5150047 | 24 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 5314401 | 25 TUBE AS-WATER | 1 | |
| 5314404 | 26 TUBE AS-WATER | 1 | |
| 5197321 | 27 HOSE AS-WATER | 1 | |
| 5197322 | 28 HOSE AS-WATER | 1 | |
| 5212599 | 29 TUBE AS | 1 | |
| 5258054 | 30 HOSE & TUBE AS | 1 | |
| 5258056 | 31 HOSE & TUBE AS | 1 | |
| 0S1588 | 32 BOLT (3/8-16X1.25-IN) | 2 | |
| 0S1590 | 33 BOLT (3/8-16X2-IN) | 3 | |
| 0S1608 | 34 BOLT (3/8-16X3.75-IN) | 4 | |
| 0S1617 | 35 BOLT (5/16-18X0.75-IN) | 1 | |
| 1401823 | 36 SPACER (11X19.05X10.5-MM THK) | 1 | |
| 1808424 | 37 SEAL-O-RING | 2 | |
| 1D4533 | 38 BOLT (1/4-20X2.25-IN) | 4 | |
| 2918145 | 39 SEAL-O-RING | 4 | |
| 2949072 | 40 SEAL-O-RING | 20 | |
| 2P1293 | 41 LOCKNUT (1-3/16-12-THD) | 2 | |
| 3B1915 | 42 BOLT (3/8-16X1.375-IN) | 2 | |
| 3E9865 | 43 LOCKNUT (1/4-20-THD) | 4 | |
| 4K0684 | 44 WASHER-HARD (34X55X6-MM THK) | 1 | |
| 5M2894 | 45 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P0537 | 46 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 5S0003 | 47 NUT (5/16-18-THD) | 1 | |
| 5T9400 | 48 SPACER (12X25X8.5-MM THK) | 1 | |
| 6V3251 | 49 SEAL-O-RING | 2 | |
| 6V5063 | 50 SEAL-O-RING | 1 | |
| 6V5064 | 51 SEAL-O-RING | 2 | |
| 6V6609 | 52 SEAL-O-RING | 1 | |
| 6V8635 | 53 CONNECTOR | 1 | |
| 6V8640 | 54 CONNECTOR | 2 | |
| 6V8791 | 55 TEE-FACE SEAL | 1 | |
| 6V9002 | 56 ELBOW (45-DEG) | 1 | |
| 6V9004 | 57 ELBOW (45-DEG) | 1 | |
| 6V9160 | 58 TEE-FACE SEAL | 1 | |
| 9X6458 | 59 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 6V9853 | 60 ELBOW (90-DEG) | 2 | |
| 9M1974 | 61 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9S8752 | 62 NUT-FULL (3/8-16-THD) | 2 |
