Assembly
100%

425-5573 SUPPORT GP-RADIATORS/N E961-UP

Group No: 425-5573
Part NumberPart NameQty
26735071 WASHER-HARD (26X47X12-MM THK)4
27859212 PLUG2
34456753 NUT (M10X1.5-THD)4
41745484 BRACKET AS2
8T3597NUT-WELD (M12X1.75-THD)6
8T3612NUT-WELD (M8X1.25-THD)4
41745645 PLATE AS1
7T1099LINK3
8T3490NUT-WELD (M10X1.5-THD)2
8T3597NUT-WELD (M12X1.75-THD)7
42555197 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
8T3597NUT-WELD (M12X1.75-THD)3
42555208 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)1
8T3597NUT-WELD (M12X1.75-THD)3
2125595SPACER (13.5X30X6-MM THK)1
42555219 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)4
8T3612NUT-WELD (M8X1.25-THD)6
425552210 BRACKET AS1
8T3490NUT-WELD (M10X1.5-THD)4
8T3612NUT-WELD (M8X1.25-THD)6
425555211 PLATE AS1
7T1099LINK3
8T3490NUT-WELD (M10X1.5-THD)6
8T3612NUT-WELD (M8X1.25-THD)3
425555312 PLATE AS1
7T1099LINK7
8T3490NUT-WELD (M10X1.5-THD)6
8T3612NUT-WELD (M8X1.25-THD)3
425555413 PLATE AS1
5D9629ROD1
8T3597NUT-WELD (M12X1.75-THD)4
8T3612NUT-WELD (M8X1.25-THD)2
425555514 SHROUD AS1
5D9629ROD2
8T3612NUT-WELD (M8X1.25-THD)2
425555615 SHROUD AS1
8T3612NUT-WELD (M8X1.25-THD)3
425557216 SHROUD AS1
6V4604RIVET-POP9
5P107617 WASHER-HARD (13.5X30X4-MM THK)20
5P411618 WASHER-HARD (8.8X20.5X2-MM THK)15
7X257619 BOLT (M24X3X70-MM)4
7X772920 WASHER (11X25X3-MM THK)24
8T413721 BOLT (M10X1.5X20-MM)4
8T419422 BOLT (M12X1.75X50-MM)4
8T419523 BOLT (M10X1.5X30-MM)16
8T419624 BOLT (M10X1.5X35-MM)4
8T422225 WASHER-PLATED (11X32X2.5-MM THK)4
8T490826 BOLT (M8X1.25X25-MM)11
8T495627 BOLT (M12X1.75X35-MM)16
8T754728 BOLT (M8X1.25X30-MM)4
9R262029 PLUG2
123382730 SEAL (15-CM EACH)
123382730A SEAL (99-CM EACH)
123382730B SEAL (128-CM)
