System And Components
487-3016 VALVE GP-BANK 7 -FRONTS/N B541-UP
Group No: 487-3016
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3K0360 | 1 SEAL-O-RING | 7 | |
| 3T0849 | 2 BOLT-SOCKET HEAD (M6X1X25-MM) | 28 | |
| 8T0267 | 3 BOLT-SOCKET HEAD (M6X1X12-MM) | 14 | |
| 4J7533 | 4 SEAL-O-RING | 7 | |
| 5B9318 | 5 BALL | 7 | |
| 6E3007 | 6 SPRING | 7 | |
| 6L9716 | 7 PLUG-PIPE | 1 | |
| 8T4121 | 8 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 1063659 | 9 PISTON | 5 | |
| 1063660 | 10 PISTON | 2 | |
| 2124961 | 11 SPRING | 7 | |
| 2429264 | 12 PLUG-ORIFICE | 7 | |
| 2432965 | 13 SPOOL | 7 | |
| 2442579 | 14 PLUG | 7 | |
| 2463193 | 15 ROD | 4 | |
| 2731871 | 16 COVER | 1 | |
| 2929221 | 17 PLUG AS | 1 | |
| 2929220 | PLUG | 1 | |
| 2948055 | SEAL-O-RING | 1 | |
| 3014568 | 18 ORIFICE | 1 | |
| 3183036 | 19 VALVE GP-CHECK & RELIEF (SCARIFIER) | 1 | |
| 3183040 | 20 VALVE GP-CHECK & RELIEF (BLADE TIP) | 1 | |
| 3183040 | 20A VALVE GP-CHECK & RELIEF (SIDESHIFT) | 1 | |
| 3183052 | 21 VALVE GP-CHECK & RELIEF (PLOW LIFT) | 1 | |
| 3183115 | 22 VALVE GP-CHECK (BLADE TIP) | 1 | |
| 3183115 | 22A VALVE GP-CHECK (SIDESHIFT) | 1 | |
| 3183115 | 22B VALVE GP-CHECK (CENTERSHIFT) | 2 | |
| 3183115 | 22C VALVE GP-CHECK (WHEEL LEAN) | 2 | |
| 3183115 | 22D VALVE GP-CHECK (SCARIFIER) | 1 | |
| 3183115 | 22E VALVE GP-CHECK (PLOW LIFT) | 1 | |
| 6V6580 | SEAL-O-RING | 1 | |
| 9X7745 | SEAL-O-RING | 1 | |
| 4716294 | SEAL-O-RING | 1 | |
| 3366718 | 23 LOCKNUT-FLANGE | 7 | |
| 3445675 | 24 NUT (M10X1.5-THD) | 4 | |
| 3664699 | 25 PLUG AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603692 | PLUG (9/16-18-THD) | 1 | |
| 3664700 | 26 PLUG AS | 18 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 3603693 | PLUG (3/4-16-THD) | 1 | |
| 3676001 | 27 PLUG AS | 5 | |
| 4J7533 | SEAL-O-RING | 1 | |
| 3603675 | PLUG (5/16-24-THD) | 1 | |
| 3676002 | 28 PLUG AS | 7 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 3676003 | 29 PLUG AS | 6 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 5646716 | 30 COVER-SPRING | 7 | |
| 3708979 | 31 COVER | 7 | |
| 3720918 | 32 SEAL-INTEGRAL | 5 | |
| 3800794 | 33 RETAINER | 28 | |
| 5266377 | 34 SPRING | 6 | |
| 3800820 | 35 SPRING | 1 | |
| 3800821 | 36 SPRING | 1 | |
| 2S4663 | 37 SEAL-O-RING | 14 | |
| 2781799 | 38 VALVE GP-SOLENOID (PLOW LIFT) | 2 | |
| 2781799 | 38A VALVE GP-SOLENOID (SCARIFIER) | 2 | |
| 2781799 | 38B VALVE GP-SOLENOID (WHEEL LEAN) | 2 | |
| 2781799 | 38C VALVE GP-SOLENOID (CIRCLE DRIVE) | 2 | |
| 2781799 | 38D VALVE GP-SOLENOID (CENTERSHIFT) | 2 | |
| 2781799 | 38E VALVE GP-SOLENOID (SIDESHIFT) | 2 | |
| 2781799 | 38F VALVE GP-SOLENOID (BLADE TIP) | 2 | |
| 3825517 | 39 MANIFOLD-INLET | 1 | |
| 3720918 | SEAL-INTEGRAL | 8 | |
| 3823290 | VALVE GP-CONTROL (BLADE TIP) | 1 | |
| 3823294 | VALVE GP-CONTROL (CENTERSHIFT) | 1 | |
| 3823298 | VALVE GP-CONTROL (LIFT) | 1 | |
| 3823300 | VALVE GP-CONTROL (SCARIFIER) | 1 | |
| 3823301 | VALVE GP-CONTROL (BLADE TIP) | 1 | |
| 3823305 | VALVE GP-CONTROL (WHEEL LEAN) | 1 | |
| 3823316 | VALVE GP-CONTROL (CIRCLE) | 1 | |
| 4714231 | KIT-SEAL (CHECK VALVE) | 1 |
