System And Components
536-6624 CAB GP-ENCLOSED ROPSS/N SGW1-363
Group No: 536-6624
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1728591 | 1 NUT-CLIP (M6X1-THD) | 3 | |
| 6V8928 | 2 HOOK-COAT | 1 | |
| 1107524 | 3 BUTTON | 42 | |
| 2808618 | 4 HAMMER | 1 | |
| 3461061 | 5 BRACKET AS | 1 | |
| 3923981 | 6 WINDOW GP-DOOR (RH) | 1 | |
| 4594602 | 7 PLUG | 4 | |
| 5254892 | 8 ROPS GP-ENCLOSED | 1 | |
| 3915325 | 9 PLATE | 1 | |
| 3915326 | 10 GASKET | 1 | |
| 5400548 | 11 DOOR GP-CAB (LH) | 1 | |
| 1548079 | 12 NUT-RETAINER | 2 | |
| 3E8020 | 13 SCREW-TRUSS HEAD (M6X1X25-MM) | 1 | |
| 6V2317 | 14 BOLT (M8X1.25X30-MM) | 4 | |
| 7Y3173 | 15 SCREW-BUTTON HEAD (M4X0.7X12-MM) | 2 | |
| 8D6542 | 16 GROMMET | 9 | |
| 8P6364 | 17 PLUG | 2 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X2039 | 19 SCREW-TRUSS HEAD (M10X1.5X35-MM) | 6 | |
| 9X2044 | 20 SCREW-TRUSS HEAD (M6X1X16-MM) | 13 | |
| 8T4122 | 21 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4179 | 23 BOLT (M12X1.75X20-MM) | 8 | |
| 8T4190 | 24 BOLT (M16X2X25-MM) | 4 |
