System And Components
521-5057 CONTROL GP-AIR STARTING -AIR HORN, AUTO LUBES/N RB41-UP
Group No: 521-5057
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D6998 | 1 HORN GP-AIR | 1 | |
| 3R4825 | 2 VALVE GP-AIR CONTROL (AIR TANK DRAIN) | 1 | |
| 5F5434 | 3 VALVE AS-VENT (AIR START) | 2 | |
| 2219576 | 4 VALVE GP-SOLENOID (24-VOLT)(AIR STARTING) | 1 | |
| 2219576 | 4A VALVE GP-SOLENOID (24-VOLT)(AUTOLUBE ACTUATION) | 1 | |
| 2219578 | KIT-VALVE | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 5D5569 | CONNECTOR | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 4318064 | 5 ADAPTER | 2 | |
| 0039163 | 6 ELBOW | 1 | |
| 0308370 | 7 ADAPTER-PIPE | 1 | |
| 1093001 | 8 STUD-TAPERLOCK (M10X1.5X65-MM) | 1 | |
| 1095605 | 9 ADAPTER-PIPE | 2 | |
| 1276241 | 10 SPACER (12X16X42-MM THK) | 1 | |
| 1358577 | 11 BOLT AS | 2 | |
| 1358578 | 12 BOLT AS | 8 | |
| 1415746 | 13 SENSOR GP-PRESSURE (AIR SYSTEM) | 1 | |
| 1444613 | 14 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1600980 | 15 BLOCK | 1 | |
| 1722404 | 16 FILM-INSTRUCTION (AIR TANK WATER DRAIN) | 1 | |
| 1745907 | 17 CLIP | 11 | |
| 1850008 | 18 VALVE GP-SOLENOID (24-VOLT)(AIR HORN) | 1 | |
| 1984777 | 19 WASHER-HARD (11X25X10-MM THK) | 1 | |
| 1984778 | 20 WASHER-HARD (13.5X30X12-MM THK) | 4 | |
| 2006345 | 21 SADDLE-MOUNTING (DUAL SWIVEL) | 1 | |
| 2042281 | 22 STRAP-CABLE | 2 | |
| 2147566 | 23 SEAL-O-RING | 1 | |
| 2174168 | 24 GOVERNOR AS | 1 | |
| 2S2923 | COVER AS | 1 | |
| 2K8198 | SEAL-O-RING | 1 | |
| 2287088 | 25 SEAL-O-RING | 4 | |
| 2287089 | 26 SEAL-O-RING | 4 | |
| 2287092 | 27 SEAL-O-RING | 3 | |
| 2636342 | 28 CLIP | 21 | |
| 2815933 | 29 ELBOW AS | 1 | |
| 6V9853 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2815979 | 30 ELBOW AS | 1 | |
| 6V9007 | ELBOW | 1 | |
| 2287092 | SEAL-O-RING | 1 | |
| 2385082 | SEAL-O-RING | 1 | |
| 2958716 | 31 HOSE AS | 1 | |
| 2968255 | 32 HOSE AS | 1 | |
| 2977976 | 33 ELBOW AS | 1 | |
| 6V9850 | ELBOW | 1 | |
| 2287089 | SEAL-O-RING | 1 | |
| 2D7325 | 34 TEE-PIPE | 1 | |
| 2F1336 | 35 FITTING-HEAD | 1 | |
| 2H9523 | 36 GROMMET | 1 | |
| 2H9524 | 37 GROMMET | 1 | |
| 2T2169 | 38 ELBOW | 1 | |
| 2T3019 | 39 CLIP (LOOP) | 3 | |
| 2Y3812 | 40 CLIP | 1 | |
| 3023908 | 41 SPACER (11X20X30-MM THK) | 1 | |
| 3028496 | 42 CONNECTOR | 1 | |
| 3091906 | 43 STUD-TAPERLOCK (M10X1.5X55-MM) | 1 | |
| 3196225 | 44 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3293356 | 45 NUT (M12X1.75-THD) | 4 | |
| 3309763 | 46 CONNECTOR AS | 1 | |
| 8C6872 | CONNECTOR | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3399752 | 47 PLATE | 1 | |
| 3445673 | 48 NUT (M6X1-THD) | 4 | |
| 3445675 | 49 NUT (M10X1.5-THD) | 14 | |
| 3469262 | 50 TUBE AS | 1 | |
| 3470574 | 51 HOSE AS | 1 | |
| 3526494 | 52 ADAPTER AS | 2 | |
| 8C6865 | CONNECTOR | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3668510 | 53 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3674895 | 54 HOSE AS | 1 | |
| 3893737 | 55 ELBOW AS | 3 | |
| 2T1922 | ELBOW | 1 | |
| 2287090 | SEAL-O-RING | 1 | |
| 3920796 | 56 ELBOW AS | 1 | |
| 6V9849 | ELBOW | 1 | |
| 2287088 | SEAL-O-RING | 1 | |
| 3B6553 | 57 ELBOW | 1 | |
| 3B7738 | 58 FITTING | 1 | |
| 3B8822 | 59 ELBOW | 1 | |
| 3D7587 | 60 ELBOW | 4 | |
| 3E4319 | 61 STUD-TAPERLOCK (M12X1.75X55-MM) | 4 | |
| 3E7448 | 62 CONNECTOR | 1 | |
| 3L7055 | 63 CONNECTOR-PIPE | 1 | |
| 4195646 | 64 HOSE AS | 1 | |
| 4252598 | 65 PLATE | 1 | |
| 4488766 | 66 AIR DRYER GP | 1 | |
| 4495301 | 67 HOSE AS | 1 | |
| 4495303 | 68 HOSE AS | 1 | |
| 4495305 | 69 PLATE | 1 | |
| 4615106 | 70 HOSE AS | 1 | |
| 4699405 | 71 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4792171 | 72 BOLT AS | 25 | |
| 4792172 | 73 BOLT AS | 2 | |
| 4838988 | 74 HOSE AS | 1 | |
| 4849640 | 75 FILTER AS-GREASE | 1 | |
| 5357683 | BODY-FILTER | 1 | |
| 5357684 | BOWL-FILTER | 1 | |
| 5357685 | FILTER AS | 1 | |
| 5958729 | SEAL-O-RING | 1 | |
| 4883974 | 76 BOLT AS | 1 | |
| 4D0124 | 77 ELBOW | 2 | |
| 4D0577 | 78 ELBOW | 1 | |
| 4D7388 | 79 CLIP | 2 | |
| 4H6147 | 80 CONNECTOR | 2 | |
| 4L9337 | 81 BOLT (3/8-16X1.5-IN) | 1 | |
| 4M5281 | 82 BOLT (1/4-20X0.75-IN) | 2 | |
| 4N3411 | 83 VALVE GP-RELAY (AIR STARTING MOTOR) | 1 | |
| 4S4455 | 84 CLIP | 4 | |
| 4S7606 | 85 ELBOW | 2 | |
| 5000506 | 86 PLATE AS | 1 | |
| 5050441 | 87 HOSE AS | 1 | |
| 5050442 | 88 HOSE AS | 1 | |
| 5077647 | 89 PUMP GP-LUBRICATION | 1 | |
| 5175526 | 90 HOSE AS | 1 | |
| 5175527 | 91 HOSE AS | 1 | |
| 5175528 | 92 HOSE AS | 1 | |
| 5193825 | 93 HOSE AS | 1 | |
| 5209029 | 94 PLATE | 1 | |
| 5215556 | 95 VALVE AS | 1 | |
| 4809716 | MANIFOLD | 1 | |
| 4822531 | VALVE AS | 1 | |
| 5234289 | 96 HOSE AS | 1 | |
| 5334159 | 97 BOLT AS | 1 | |
| 5416633 | 98 CLIP (LOOP) | 1 | |
| 5416637 | 99 CLIP (LOOP) | 3 | |
| 5738542 | 100 HOSE AS | 1 | |
| 5889755 | 101 PLATE AS | 1 | |
| 3662273 | PLATE | 1 | |
| 5889756 | 102 HOSE AS | 1 | |
| 5889757 | 103 HOSE AS | 1 | |
| 5D7132 | 104 CLAMP | 2 | |
| 5D7133 | 105 BRACKET | 1 | |
| 5H4778 | 106 ELBOW | 3 | |
| 5P4116 | 107 WASHER-HARD (8.8X20.5X2-MM THK) | 3 | |
| 5P7854 | 108 CLIP (LOOP) | 1 | |
| 5P9297 | 109 CLIP (LOOP) | 1 | |
| 5T6374 | 110 SPACER (11X20X40-MM THK) | 1 | |
| 6B9081 | 111 BUSHING-REDUCER | 1 | |
| 6B9664 | 112 VALVE-AIR RELIEF | 1 | |
| 5240073 | VALVE-AIR RELIEF | 1 | |
| 6D3479 | 113 CLIP (LOOP) | 2 | |
| 6D4244 | 114 CLIP (LOOP) | 5 | |
| 6K1019 | 115 NIPPLE-PIPE | 2 | |
| 6K8178 | 116 CLIP (LOOP) | 3 | |
| 6V6782 | 117 CLIP (SLOT) | 1 | |
| 6V6783 | 118 CLIP (TAB) | 1 | |
| 6V8994 | 119 UNION (STRAIGHT) | 1 | |
| 6V9168 | 120 NUT (11/16-16-THD) | 1 | |
| 7D6936 | 121 VALVE AS-CHECK (AIR TANK) | 1 | |
| 7G8839 | 122 SPACER (13.5X57X6-MM THK) | 2 | |
| 7T8331 | 123 MOUNT AS | 2 | |
| 7X2533 | 124 BOLT (M6X1X35-MM) | 2 | |
| 7X2535 | 125 BOLT (M6X1X60-MM) | 2 | |
| 7X2537 | 126 BOLT (M8X1.25X35-MM) | 1 | |
| 7X5331 | 127 ELBOW | 3 | |
| 7X7729 | 128 WASHER (11X25X3-MM THK) | 2 | |
| 8B2664 | 129 BUSHING-REDUCER | 1 | |
| 8B9913 | 130 ELBOW-REDUCING | 1 | |
| 8C6866 | 131 CONNECTOR | 1 | |
| 8C6868 | 132 CONNECTOR | 1 | |
| 8D4765 | 133 REGULATOR | 1 | |
| 8E9571 | 134 WASHER-HARD (8.8X16X7-MM THK) | 2 | |
| 8S0948 | 135 CLIP | 1 | |
| 8S7169 | 136 COUPLING | 1 | |
| 8T0722 | 137 BOLT-LOCKING (M10X1.5X30-MM) | 1 | |
| 8T4121 | 138 WASHER-HARD (11X21X2.5-MM THK) | 21 | |
| 8T4137 | 139 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4186 | 140 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4192 | 141 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4205 | 142 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 8T4223 | 143 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4224 | 144 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T4896 | 145 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T4910 | 146 BOLT (M12X1.75X60-MM) | 2 | |
| 8T6466 | 147 BOLT (M10X1.5X60-MM) | 3 | |
| 8T6757 | 148 PLUG-PIPE | 4 | |
| 8T6870 | 149 BOLT (M8X1.25X70-MM) | 2 | |
| 8T9043 | 150 BOLT (5/16-18X0.875-IN) | 3 | |
| 8T9364 | 151 BOLT (1/4-20X0.625-IN) | 2 | |
| 9B7237 | 152 BOLT (3/8-16X1.25-IN) | 1 | |
| 9C5344 | 153 SPACER (10.5X20X18-MM THK) | 2 | |
| 9M7357 | 154 COUPLING AS | 1 | |
| 9X2398 | 155 ELBOW | 3 | |
| 9X3495 | 156 CLIP AS | 1 | |
| 9X6165 | 157 WASHER (6.5X22X2.5-MM THK) | 2 | |
| 9X8256 | 158 WASHER (6.6X12X2-MM THK) | 2 | |
| 7C5105 | KIT-VALVE SEAL (AIR STARTING) | 1 | |
| 5400200 | KIT-O-RING | 1 |
