System And Components
1W-5291 LINES GP-AIR COMPRESSORS/N 7EB1-99999; 6DC1-UP
Group No: 1W-5291
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0307949 | 1 ELBOW | 1 | |
| 2M9780 | 2 SEAL-O-RING | 1 | |
| 2N8037 | 3 ELBOW | 1 | |
| 2W8167 | 4 TUBE AS | 1 | |
| 2N1287 | 5 ELBOW-FLARED | 3 | |
| 2W8169 | 6 TUBE AS-OIL | 1 | |
| 4B3388 | 7 BOLT (5/16-18X1.125-IN) | 2 | |
| 9M1974 | 8 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 1D4541 | 9 BOLT (5/16-18X3-IN) | 2 | |
| 1D4716 | 10 NUT-FULL (5/16-18-THD) | 2 | |
| 7W1523 | 11 BRACKET | 1 | |
| 0321269 | 12 ELBOW | 1 | |
| 2W8168 | 13 TUBE AS-OUTLET | 1 | |
| 5P0078 | TUBE | ||
| 0115224 | 14 BUSHING-REDUCING | 1 | |
| 7J0482 | 15 ELBOW | 1 | |
| 8M0755 | 16 ADAPTER | 2 | |
| 2W8181 | 17 TUBE AS | 1 | |
| 6B4661 | 18 BUSHING-REDUCER | 1 | |
| 8L3282 | 19 CONNECTOR | 1 | |
| 3J5390 | 20 PLUG | 2 | |
| 5M6214 | 21 PLUG-PIPE | 1 | |
| 1P7125 | 22 GOVERNOR AS-AIR COMPRESSOR | 1 | |
| 2S2923 | 23 COVER AS | 1 | |
| 2K8198 | SEAL-O-RING | 1 | |
| 9F2247 | 24 PLUG-PIPE | 5 | |
| 2W8171 | 25 TUBE AS-GOVERNOR | 1 | |
| 5F5434 | 26 VALVE AS-VENT | 1 | |
| 9L5125 | 27 ELBOW | 1 | |
| 9M0402 | KIT-GOVERNOR OVERHAUL (AIR COMPRESSOR) | 1 |
