System And Components
8N-7250 FILTER GP-FUEL -LHFRONT OIL SUMP
Group No: 8N-7250
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W3587 | 1 TUBE AS | 1 | |
| 8N2755 | 2 CLAMP | 12 | |
| 7K3377 | 3 PIPE | 5 | |
| 0S1608 | 4 BOLT (3/8-16X3.75-IN) | 5 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 12 | |
| 1W3588 | 6 TUBE AS | 1 | |
| 2P7636 | 7 CONNECTOR (3/4-16 STR-THD) | 1 | |
| 3K0360 | 8 SEAL-O-RING | 2 | |
| 0L1352 | 9 BOLT (3/8-16X3.25-IN) | 2 | |
| 1D4717 | NUT (3/8-16-THD) | 2 | |
| 0L2070 | 10 BOLT (3/8-16X2.25-IN) | 1 | |
| 9M4584 | 11 CONNECTOR | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 8N8266 | 12 SUPPORT AS-FUEL FILTER | 1 | |
| 7N1294 | 13 SWITCH AS-DIFF PRESSURE (FUEL) | 1 | |
| 2M9780 | SEAL-O-RING (LARGE) | 1 | |
| 4D2297 | SEAL-O-RING (SMALL) | 1 | |
| 1P7625 | 14 ELBOW | 1 | |
| 1N3812 | 15 TUBE AS | 1 | |
| 1W7826 | 16 TUBE AS | 1 | |
| 0038581 | 17 TEE-UNION | 1 | |
| 1N4734 | 18 CLAMP | 4 | |
| 1A2029 | 19 BOLT (3/8-16X1.125-IN) | 2 | |
| 5M6213 | 20 PLUG-PIPE (1/4-18-THD) | 3 | |
| 8N3483 | 21 ADAPTER-PUMP | 1 | |
| 1W7559 | 22 BASE AS-FUEL FILTER | 1 | |
| 6N1127 | SHIELD | 1 | |
| 7F9090 | SCREW-DRIVE (NO 8X3/8-IN) | 2 | |
| 3B1915 | 23 BOLT (3/8-16X1.375-IN) | 3 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 9 | |
| 0L2070 | 25 BOLT (3/8-16X2.25-IN) | 2 | |
| 8N7054 | 26 SUPPORT | 1 | |
| 1W3589 | 27 TUBE AS | 1 | |
| 2P7636 | 28 CONNECTOR (3/4-16 STR-THD) | 1 | |
| 3K0360 | 29 SEAL-O-RING | 2 | |
| 2K8198 | 30 SEAL-O-RING | 2 | |
| 8N3080 | 31 FILTER-FUEL | 1 | |
| 1W5577 | 32 TUBE AS | 1 | |
| 1W5578 | 33 TUBE AS | 1 | |
| 5P4900 | 34 ELBOW-FLARED | 2 | |
| 9S4185 | 35 PLUG (3/4-16-THD) | 1 |
