System And Components
8X-9440 HORN GP-AIRS/N 6NM1-UP
Group No: 8X-9440
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V3342 | 1 ELBOW-PIPE | 1 | |
| 7T9074 | 2 VALVE GP-SOLENOID (24-VOLT) | 1 | |
| 9G9150 | 3 CLIP | 1 | |
| 7I4696 | 4 RETAINER | 1 | |
| 7I4698 | 5 RING | 1 | |
| 7I4699 | 6 INSULATOR | 1 | |
| 3G1701 | 7 SPRING | 1 | |
| 0987467 | 8 BUTTON | 1 | |
| 0919071 | 9 SEAL-HORN BUTTON | 1 | |
| 7I4697 | 10 PIN | 3 | |
| 0094185 | 11 BRUSH-HORN | 4 | |
| 0094184 | 12 SPRING-HORN | 4 | |
| 5H4778 | 13 ELBOW | 1 | |
| 4D2847 | 14 HOSE AS | 1 | |
| 5D6998 | 15 HORN GP-AIR | 1 | |
| 4H6147 | 16 CONNECTOR | 1 | |
| 4B3388 | 17 BOLT (5/16-18X1.125-IN) | 1 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 5S0003 | 19 NUT (5/16-18-THD) | 1 | |
| 4L6454 | 20 BOLT (3/8-16X1-IN) | 4 | |
| 8T4896 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 8X9387 | 22 PLATE | 1 | |
| 5K2408 | 23 FITTING | 1 | |
| 8W1979 | 24 WIRE AS | 1 | |
| 5T4030 | 25 BRACKET | 1 | |
| 6V8801 | 26 NUT (3/8-16-THD) | 1 | |
| 9L1566 | 27 SUPPORT | 1 |
