Assembly
100%

8X-1940 LIFT GP-BLADES/N 2AN1-UP

Group No: 8X-1940
Part NumberPart NameQty
8T42231 WASHER-HARD (13.5X25.5X3-MM THK)4
8T89192 BOLT (1/2-13X1.75-IN)4
7D88913 RETAINER2
8X46504 ARM AS1
7D88895 BEARING (76.35-MM ID)1
8D81686 BEARING (63.65-MM ID)1
6V81827 NUT (3/4-10-THD)4
8C8842BOLT (3/4-10X4-IN)4
8T49948 WASHER-HARD (20X36.5X3.5-MM THK)8
8X46449 STUD-BALL1
9D153110 PIN2
8X511011 YOKE AS2
2G8233RING1
2M084912 WASHER-HARD (13.5X25.5X5-MM THK)1
9S1366BOLT (1/2-13X2.5-IN)1
8X502813 BAR AS1
8X502114 BEARING2
8T412215 WASHER-HARD (17X32X3.5-MM THK)4
7X035116 BOLT (5/8-11X3.75-IN)4
9D275317 LOCK2
7H244418 SEAL-O-RING2
7D887819 WASHER-THRUST (3.015X4.22X0.075-IN THK)4
7D887720 WASHER-THRUST (77.77X107.19X2.39-MM THK)2
7D887921 SHIM (0.127-MM THK)8
7D888122 SHIM (0.254-MM THK)6
7D888223 SHIM (0.508-MM THK)2
7D887524 WASHER-THRUST (2.515X3.62X0.075-IN THK)4
5F014925 SEAL-O-RING2
7D888326 SEAL2
8X488427 PIN1
7K920328 SEAL-LIP TYPE4
7D887629 WASHER-THRUST (65.07X92.08X2.39-MM THK)2
8X288130 LOCK2
7D888431 SEAL2
8X464932 ARM AS1
8D8168BEARING (63.65-MM ID)1
7D8889BEARING (76.35-MM ID)1
129726133 PLATE1
9D153034 WASHER-THRUST (2.265X4.5X0.075-IN THK)(1.90MM THK)2
1240360WASHER-THRUST (57.5X114.3X1-MM THK)(1MM THK)2
