System And Components
222-2310 AIR COMPRESSOR GP -150 SAEALSO AN ATTACHMENT
Group No: 222-2310
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C1809 | 1 SPACER (8X19X6.5-MM) | 2 | |
| 5D1026 | 2 CLAMP-BAND | 4 | |
| 6I0233 | 3 NUT (M12X1.75-THD) | 3 | |
| 6I0254 | 4 BOLT (M8X1.25X30-MM) | 2 | |
| 6I0302 | 5 BOLT (M10X1.5X25-MM) | 2 | |
| 6I0654 | 6 BOLT (M10X1.5X25-MM) | 2 | |
| 7M7410 | 7 PLUG-PIPE | 1 | |
| 0337625 | 8 ELBOW | 1 | |
| 0358017 | 9 UNION | 2 | |
| 1134616 | 10 CONNECTOR | 4 | |
| 1243815 | 11 BOLT (M8X1.25X16-MM) | 3 | |
| 1263204 | 12 GEAR (28-TEETH) | 1 | |
| 1263205 | 13 BRACKET | 1 | |
| 1263206 | 14 HUB | 1 | |
| 1263207 | 15 SEAL-O-RING | 1 | |
| 1263208 | 16 BEARING | 1 | |
| 1263209 | 17 GEAR (32-TEETH) | 1 | |
| 1263210 | 18 PLATE | 1 | |
| 1263211 | 19 BOLT | 3 | |
| 1263212 | 20 BOLT (M8X1.25X25-MM) | 4 | |
| 1263215 | 21 HOSE | 1 | |
| 1263216 | 22 STUD | 1 | |
| 1263217 | 23 STUD | 1 | |
| 1263219 | 24 SEAL-O-RING | 1 | |
| 1283829 | 25 TUBE AS | 1 | |
| 1030173 | 25A CLIP | 1 | |
| 1283830 | 26 HOSE | 1 | |
| 1283831 | 27 BRACKET | 1 | |
| 1394735 | 28 AIR COMPRESSOR GP | 1 | |
| 1394736 | 29 CRANKSHAFT-COMPRESSOR | 1 | |
| 1394737 | 30 COVER | 1 | |
| 1988262 | 31 COVER AS | 1 | |
| 1988263 | 31A SEAL-O-RING | 1 | |
| 1284300 | KIT-AIR COMPRESSOR | 1 | |
| 1284302 | KIT-AIR COMPRESSOR | 1 | |
| 1284303 | KIT-COMPRESSOR VALVE | 1 |
